FTA-80-223-H

Power Line Filter Modules Overview

The Cosel USA, Inc. FTA-80-223-H is a high-performance power line filter module designed for chassis mounting applications. It features a robust construction capable of handling significant electrical loads while providing effective electromagnetic interference (EMI) suppression. The unit is rated for a continuous current of 80 Amperes and supports operating voltages up to 500 VAC. Key electrical parameters include a maximum leakage current of 0.022 µF at the specified test conditions. The device utilizes screw termination methods for secure electrical connections, ensuring reliability in demanding industrial environments where stable power quality is critical.

Power Line Filter Modules Feature Summary

• Provides high attenuation filtering for power line noise reduction
• Designed for secure chassis mount installation
• Utilizes screw termination for reliable electrical connectivity

Power Line Filter Modules Applications

• Industrial machinery power supply input stages
• Medical equipment requiring strict EMI compliance
• Telecommunications infrastructure power systems

Power Line Filter Modules Procurement Notes

Verify the specific suffix 'H' against official Cosel documentation to confirm exact terminal configuration and certification status. Ensure the required 80A current rating and 500VAC voltage tolerance align with your system design constraints before ordering. Cross-reference the datasheet for precise mechanical dimensions to validate chassis mounting compatibility.

Power Line Filter Modules Selection Notes

Select this component when high current capacity is required alongside stringent EMI suppression standards. Compare the 80A rating against peak load requirements to prevent thermal overload. Consider the chassis mount form factor if panel integration is preferred over PCB mounting alternatives within the FTA-80 series.

Power Line Filter Modules Part Context

This model belongs to the Cosel FTA-80 series of power line filters, which are engineered for heavy-duty industrial use. The series offers various attenuation levels and current ratings, with the 223 variant specifically tuned for its capacitance and leakage characteristics. It serves as a critical interface between noisy power sources and sensitive downstream electronics.

Power Line Filter Modules Replacement Considerations

Consult official Cosel substitution guides for direct equivalents. Verify that any alternative maintains the 80A current rating and 500VAC voltage class. Ensure mechanical footprint and screw terminal spacing match existing mounting hardware to avoid redesign efforts.
