FTMH-135-02-L-DH-K

Headers, Male Pins Overview

The FTMH-135-02-L-DH-K is a surface mount board-to-board connector from Samtec's CLM series. It features 70 positions arranged in two rows with a 1.00mm (0.039 inch) pitch. The connector utilizes phosphor bronze contacts with gold plating for the mating interface and tin plating for the termination. Rated for 3.1A per contact and 270VAC/382VDC, it operates within a temperature range of -55°C to 125°C. The housing is made of black liquid crystal polymer (LCP) with UL94 V-0 flammability rating.

Headers, Male Pins Feature Summary

• Push-pull latching mechanism for secure connection
• Surface mount termination for automated assembly
• Gold-plated mating contacts for reliable conductivity

Headers, Male Pins Applications

• High-density board-to-board interconnections
• Industrial control systems requiring push-pull retention
• Telecommunications equipment backplanes

Headers, Male Pins Procurement Notes

Verify the specific suffix 'DH' indicates right-angle termination and 'K' denotes tape-and-reel packaging configuration as per Samtec official documentation. Confirm RoHS compliance status matches current manufacturing standards. Ensure EDA models correspond to the exact pin count and mechanical dimensions before integration into design files.

Headers, Male Pins Selection Notes

Select this component when high-density 1.00mm pitch connections are required alongside positive latching security. The right-angle form factor aids in space-constrained vertical stacking. Verify that the 3.1A current rating meets system power distribution requirements and that the operating temperature range aligns with environmental conditions.

Headers, Male Pins Part Context

This part belongs to the Samtec CLM family of micro terminal strips designed for compact electronic assemblies. The series offers various termination styles and contact counts to accommodate diverse layout needs while maintaining consistent electrical performance across the product line.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with Samtec engineering for potential alternatives if supply constraints exist.
