FTRA6971M5PB-001

Antennas RF Overview

The TE Connectivity FTRA6971M5PB-001 is a low-profile, omni-directional RF antenna designed for 5G applications. It features a dome shape with an N-type female connector and panel mount configuration. The operating frequency range spans from 698 MHz to 7125 MHz, supporting broad band coverage. The antenna provides a gain of 2 dBi and utilizes a phantom on-ground plane design. This component is engineered for integration into wireless infrastructure requiring compact form factors and reliable signal transmission across multiple frequency bands.

Antennas RF Feature Summary

• Omni-directional radiation pattern ensures consistent signal coverage in all horizontal directions.
• Low-profile dome design facilitates discreet installation while maintaining structural integrity.
• Integrated N-type female connector allows for secure cable attachment without additional adapters.

Antennas RF Applications

• 5G cellular base station deployments
• Wireless communication infrastructure
• Broadband access point installations

Antennas RF Procurement Notes

Verify the specific ordering suffix to confirm connector type and mounting style. Ensure compatibility with existing N-type interfaces. Confirm frequency range requirements match the 698-7125 MHz specification. Check environmental ratings if outdoor deployment is intended. Validate mechanical dimensions against enclosure constraints prior to purchase.

Antennas RF Selection Notes

Select this model when a low-profile solution is required for 5G networks. Consider the 2 dBi gain for standard coverage needs. Evaluate the panel mount option for fixed installations. Compare against higher gain variants if extended range is necessary. Ensure the N-type interface aligns with system cabling standards.

Antennas RF Part Context

This part belongs to the 5G Phantom Low-Profile On-Ground Plane series by TE Connectivity. These antennas are optimized for modern wireless infrastructure. The series offers various frequency ranges to suit different regional standards. The FTRA6971M5PB-001 specifically targets wideband operations. It represents a compact alternative to traditional whip antennas.

Antennas RF Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official TE Connectivity catalogs for cross-reference data. Verify electrical parameters before substituting with similar models. Ensure mechanical fitment matches the original design specifications.
