FTS-112-01-F-D-P

Headers, Male Pins Overview

The FTS-112-01-F-D-P is a low-profile terminal strip header from the Samtec FTS series. It features a 1.27 mm (0.050 inch) contact pitch and a dual-row configuration with 24 positions. The connector utilizes phosphor bronze terminals with gold flash over nickel plating for mating surfaces and matte tin over nickel for solder termination. Designed for through-hole vertical mounting, it supports pick-and-place assembly. The unit operates within a temperature range of -55 °C to +125 °C and carries an UL94 V-0 flammability rating for the black liquid crystal polymer insulator.

Headers, Male Pins Feature Summary

• Low-profile design optimized for space-constrained applications
• Pick-and-place pad compatibility for automated surface mount assembly
• Robust phosphor bronze contacts with durable gold flash plating

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronic modules
• Wire-to-board connections requiring high-density pin counts
• Automated manufacturing environments utilizing pick-and-place equipment

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required through-hole vertical orientation and dual-row configuration. Confirm that the gold flash over nickel plating specification aligns with environmental requirements. Ensure the PCB layout accommodates the 1.27 mm pitch and the physical dimensions of the low-profile header to prevent mechanical interference during assembly.

Headers, Male Pins Selection Notes

Select this component when a low-height profile is critical for the enclosure design. The dual-row arrangement provides higher density compared to single-row alternatives. Verify that the operating temperature range meets the system's thermal requirements. Consider the pick-and-place capability if high-volume automated production is planned.

Headers, Male Pins Part Context

This component belongs to the FTS Series, which specializes in micro low-profile terminal strips. The series offers various configurations including surface mount and through-hole options. The FTS-112-01-F-D-P specifically addresses needs for reliable, high-density interconnects in modern electronics where board space is limited.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other FTS series headers with matching 1.27 mm pitch and 24-position dual-row layouts. Ensure any replacement maintains the same through-hole vertical mounting style and compatible plating specifications.
