FTS-133-02-S-D

Headers, Male Pins Overview

The Samtec FTS-133-02-S-D is a low-profile micro header strip featuring a 1.27 mm (0.05 in) pitch and a dual-row configuration with 66 positions. Designed for surface-mount or through-hole termination, this shrouded connector utilizes phosphor bronze contacts with gold plating to ensure reliable signal transmission. It supports board-to-board applications within an operating temperature range of -55°C to +125°C. The housing is constructed from liquid crystal polymer (LCP) rated UL 94 V-0, providing high thermal stability and flame resistance for demanding electronic environments.

Headers, Male Pins Feature Summary

• Ultra-thin profile design minimizes vertical space requirements on the PCB
• Shrouded structure provides alignment and protects contact pins during mating
• Flexible mounting options support both surface-mount and through-hole assembly processes

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronic modules
• High-density mezzanine circuit interfaces
• Consumer electronics requiring low-profile stacking solutions

Headers, Male Pins Procurement Notes

Verify the specific termination style required for your assembly process, as the series offers both surface-mount and through-hole variants. Confirm that the 1.27 mm pitch aligns with your partner connector specifications. Ensure the LCP insulation material meets your thermal processing requirements. Cross-reference the exact part number suffix to distinguish between standard and specialized configurations.

Headers, Male Pins Selection Notes

Select this component when a low-height connection is critical for the device form factor. The dual-row layout maximizes I/O density within a limited footprint. Consider the shrouded design if pin protection during insertion is necessary. Verify that the gold-plated phosphor bronze contacts meet your conductivity and corrosion resistance standards for the intended operational environment.

Headers, Male Pins Part Context

This connector belongs to the FTS series, which specializes in ultra-thin header strips. The Tiger Eye branding indicates a focus on high-reliability performance. The S suffix typically denotes gold plating, while D indicates a dual-row arrangement. This series complements other Samtec interconnect solutions by offering flexible height and termination options for diverse PCB architectures.

Headers, Male Pins Replacement Considerations

Compatible substitutes include the FTSH-133-02-S-D for through-hole applications and the TFM-133-02-S-D for high-reliability terminal strips. Ensure the replacement maintains the 1.27 mm pitch and 66-position count. Verify that the shrouded design and contact material properties match the original system requirements.
