FTSH-105-01-L-DV-A

Headers, Male Pins Overview

The FTSH-105-01-L-DV-A is a high-reliability header strip manufactured by Samtec Inc. It features a 1.27 mm (0.050 inch) pitch with 10 positions arranged in two rows. The connector utilizes surface mount termination and square phosphor bronze contacts with gold plating. Rated for 3.4A per contact, it operates within a temperature range of -55°C to 125°C. The housing is constructed from black liquid crystal polymer (LCP) with UL94 V-0 flammability rating.

Headers, Male Pins Feature Summary

• High mating cycle capability designed for demanding interconnect applications
• Configurable post heights available within the FTSH series
• Supports vertical and horizontal row configurations
• Compatible with pick-and-place automated assembly processes

Headers, Male Pins Applications

• High reliability board-to-board interconnections
• Automotive electronic systems requiring robust connectivity
• Industrial equipment with frequent maintenance cycles
• Data communication hardware requiring signal integrity

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'A' corresponds to the required configuration, as variations exist within the FTSH family. Confirm the package type matches production requirements, noting that this part number may be associated with tape and reel packaging. Ensure compatibility with existing PCB footprint designs before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 1.27 mm pitch surface mount header is required for high-cycle applications. Consider the FTSH series benefits such as polarized and keyed options to prevent incorrect installation. Evaluate thermal performance requirements against the specified operating temperature range and current rating capabilities.

Headers, Male Pins Part Context

This component belongs to the FTSH High Reliability Header Strips series. The series offers extensive configurability including through-hole, surface mount, and mixed technology terminations. It meets or exceeds MIL-DTL-55302 testing standards and supports data rates up to 8 Gbps. The product line includes specialized versions like Extended Life Product and Hot Pluggable variants.

Headers, Male Pins Replacement Considerations

FTSH-105-01-L-DV-K serves as an alternative variant within the same series. Verify pin count, pitch, and termination style compatibility before substitution. Consult official Samtec documentation to confirm interchangeability regarding mechanical dimensions and electrical ratings.
