FTSH-115-04-S-DV

Headers, Male Pins Overview

The FTSH-115-04-S-DV is a high-reliability header strip manufactured by Samtec Inc. It features a 1.27mm (0.050 inch) pitch with 30 positions arranged in two rows. The connector utilizes phosphor bronze contacts with gold plating for mating surfaces and matte tin for termination, housed in a black liquid crystal polymer (LCP) insulator. Designed for surface mount installation, it supports vertical orientation and offers a rated current of 3.4A per contact. The component operates within a temperature range of -55°C to 125°C and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Configurable micro header design supporting various post heights and orientations
• High mating cycle capability suitable for demanding applications
• Surface mount termination technology for automated assembly

Headers, Male Pins Applications

• High reliability board-to-board interconnects
• Systems requiring frequent mating cycles
• Automotive electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Samtec configuration tool to ensure correct termination type, row count, and packaging format. Confirm that the selected variant matches the required PCB footprint and thermal profile specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when surface mount technology is required for high-density interconnects. Ensure the design accommodates the vertical mounting style and verify that the 1.27mm pitch aligns with the mating connector interface requirements.

Headers, Male Pins Part Context

This part belongs to the FTSH series of high-reliability header strips. The series is highly configurable, offering options for through-hole, surface mount, and mixed technology terminations. It is designed for applications requiring robust performance and precise alignment.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other FTSH series variants with identical pitch and pin count but different termination or plating options. Verify mechanical compatibility and electrical ratings before substitution.
