FTSH-140-04-S-DV-A-TR

Headers, Male Pins Overview

The FTSH-140-04-S-DV-A-TR is a high-reliability male pin header strip manufactured by Samtec. It features a 1.27 mm (0.05 in) pitch with 140 positions arranged in two rows. Designed for surface-mount installation, it utilizes solder termination and straight mounting angles. The contacts are gold-plated phosphor bronze, rated for 3.4 A current and 270 VAC voltage. Operating temperatures range from -55°C to +125°C. The housing is black liquid crystal polymer (LCP) with UL 94 V-0 flammability rating.

Headers, Male Pins Feature Summary

• High-reliability construction designed for extended life applications
• Surface-mount terminal design for automated assembly processes
• Gold-plated contact finish ensuring stable signal transmission
• Compatible with standard board-to-board interconnection requirements

Headers, Male Pins Applications

• Board-to-board interconnections
• High-cycle mating environments
• Automotive electronics systems
• Industrial control modules

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm tape-and-reel packaging configuration. Ensure the component matches the required pin count and row arrangement for the target PCB footprint. Cross-reference the datasheet for precise mechanical dimensions and thermal specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when surface-mount technology is required for high-density connections. Consider the 1.27 mm pitch for space-constrained layouts. Evaluate the gold plating thickness if corrosion resistance is critical. Confirm compatibility with mating socket strips within the same series family.

Headers, Male Pins Part Context

This part belongs to the FTSH series of high-reliability header strips. The series offers various termination options including through-hole and mixed technology configurations. It supports vertical and horizontal orientations with customizable keying options to prevent misalignment during assembly.

Headers, Male Pins Replacement Considerations

Direct substitutes include other FTSH series variants with matching pitch and position counts. Verify equivalent electrical ratings and mechanical dimensions before substitution. Consult official cross-reference lists for confirmed compatible alternatives.
