FX2400029

Crystals Overview

The FX2400029 is a ceramic crystal component manufactured by Diodes Incorporated, designed for surface-mount applications. It operates at a nominal frequency of 24.0000 MHz with a specified load capacitance of 18 pF. The device utilizes the SEAM6035 package format, which provides a compact footprint suitable for space-constrained circuit designs. This component functions as a fundamental resonator within oscillator circuits, requiring external active components to generate clock signals.

Crystals Feature Summary

• Utilizes ceramic material construction for stable mechanical resonance
• Designed for surface-mount technology (SMD) integration
• Optimized for standard load capacitance requirements

Crystals Applications

• General-purpose clock signal generation in embedded systems
• Microcontroller and microprocessor timing references
• Digital communication interface synchronization

Crystals Procurement Notes

Verify that the specific part number matches the required load capacitance of 18 pF and the 24 MHz frequency specification. Confirm compatibility with the target circuit's oscillator design parameters. Ensure the SEAM6035 package dimensions align with the printed circuit board layout constraints before finalizing procurement decisions.

Crystals Selection Notes

Select this component when a discrete ceramic resonator is preferred over integrated oscillators for cost-sensitive or flexible design architectures. Consider the external circuit complexity required to drive the crystal compared to pre-packaged XO solutions. Evaluate the thermal stability requirements against the typical performance characteristics of ceramic materials for the intended operating environment.

Crystals Part Context

This component belongs to the broader category of passive frequency control elements produced by Diodes Incorporated. Unlike active oscillators such as the FK series, it serves as a passive resonant element. It is distinct from other packages like the FK3225 or FX1600002, offering specific dimensional and electrical characteristics tailored for 24 MHz applications.
