FX919BD5

Overview

The FX919BD5 is a highly integrated data processor from CML Microcircuits, designed for telecom interface applications. It combines a Medium Access Control (MAC) unit with a 4FSK packet data modem. The device supports half-duplex communication with data rates ranging from 4800 to 19.2 kbits/sec. It operates on a supply voltage between 3.3V and 5V. The IC features excellent radio fading performance and includes built-in error detection and correction capabilities. Packaged in a 24-SSOP format, it serves as a complete modulator/demodulator solution for wireless data transmission systems requiring robust signal processing.

Feature Summary

• Integrates Medium Access Control and 4FSK packet data modulation
• Supports half-duplex operation with variable bit rates
• Includes hardware error detection and correction mechanisms
• Optimized for reliable performance in radio fading environments

Applications

• Wireless telemetry systems
• Industrial remote monitoring links
• Low-power sensor network interfaces
• Specialized two-way radio data terminals

Procurement Notes

Verify the exact suffix against the manufacturer datasheet to confirm package type and tape/reel specifications. Confirm operational voltage ranges match system requirements. Check current availability status as components may have limited stock or end-of-life implications. Ensure environmental compliance documentation aligns with target market regulations before finalizing procurement orders.

Selection Notes

Choose this component when a single-chip solution for MAC and FSK modulation is required. It suits designs needing moderate data rates up to 19.2 kbps. Consider the 24-SSOP package constraints for PCB layout. Evaluate if the integrated error correction meets link budget requirements. Compare against discrete modem solutions for size and power efficiency benefits.

Part Context

This part belongs to the FX919/MX919 series of telecom interface ICs. These devices are engineered for embedded wireless data communication tasks. The series emphasizes integration by combining protocol handling with physical layer modulation. They target applications where space and power consumption are critical design parameters for industrial and commercial wireless deployments.

Replacement Considerations

MX919BDS is a related variant within the same product family. Verify pin compatibility and electrical specifications before substitution. Ensure the replacement matches the required operating voltage and data rate capabilities. Consult official cross-reference guides for definitive interchangeability confirmation.
