G125-FS12005F1P

Overview

The Harwin G125-FS12005F1P is a Gecko-SL series rectangular cable assembly featuring a double-ended female-to-female configuration. It utilizes a 1.25 mm pitch with 20 positions at each port, constructed from 26 AWG wire. The assembly has a total length of 150 mm and supports a current rating of 2 A.

Feature Summary

• Double-ended female connector interface for direct mating applications
• Gecko-SL series design ensuring compact interconnection
• Flexible 26 AWG cabling for space-constrained routing

Applications

• Interconnecting PCBs in dense electronic modules
• Signal transmission within compact industrial equipment
• Internal wiring for consumer electronics assemblies

Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm the exact cable length and pin count, as variations exist within the Gecko-SL family. Ensure compatibility with mating connectors regarding gender and pitch before procurement. Cross-reference the datasheet for environmental ratings and RoHS compliance status relevant to your region.

Selection Notes

Select this component when a fixed-length, pre-terminated solution is required between two board-mounted receptacles. The 1.25 mm pitch suits high-density layouts where standard spacing is insufficient. Consider the 2 A current capacity and 150 mm length constraints relative to the system's mechanical envelope and electrical load requirements.

Part Context

This part belongs to the Harwin Gecko-SL product line, designed for high-density interconnects. The series offers various configurations including headers, housings, and cable assemblies. This specific model provides a ready-made connection solution, eliminating manual crimping and soldering for point-to-point links.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Evaluate other Harwin Gecko-SL cable assemblies or generic 1.25 mm pitch F/F cables if cross-brand substitution is necessary.
