G125-FV104F1-04AB000P

Overview

The G125-FV104F1-04AB000P is a Gecko-MT series PCB receptacle featuring an 8-position, 2-row configuration with a 1.25 mm board pitch. It utilizes a 4+4 power and signal contact arrangement designed for through-hole vertical mounting. The connector supports current ratings of 2A and 10A, with insulation constructed from Polyamide (PA4T) or Nylon 4T. Key mechanical features include jackscrews, a mating flange, and a polarizing key to ensure secure alignment.

Feature Summary

• Incorporates jackscrews and a mating flange for robust mechanical retention
• Features a polarizing key to prevent misalignment during assembly
• Designed with a specific 4+4 power and signal contact arrangement

Applications

• Power to the Board interconnects
• Vertical PCB throughboard connections
• High-density electronic assemblies requiring secure locking

Procurement Notes

Verify that the specific order suffix matches the required termination length and contact arrangement. Confirm compliance with RoHS and REACH standards as documented in the official datasheet. Ensure the selected variant aligns with the intended thermal and electrical requirements for the target application environment.

Selection Notes

Select this component when a secure, locked connection is required for vertical board-to-board interfaces. The Gecko-MT series offers high reliability through its screw-lock mechanism. Consider the 1.25 mm pitch and 8-position layout for space-constrained designs needing mixed power and signal routing capabilities.

Part Context

This part belongs to Harwin's Gecko-MT family, which specializes in high-reliability power connectors. The series is engineered for demanding environments where vibration resistance and secure mating are critical. The Gecko-MT line provides various position counts and termination options to support diverse industrial and commercial electronics applications.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
