G125-FV108F3-03AB000P

Overview

The Harwin G125-FV108F3-03AB000P is a Gecko-MT series PCB receptacle featuring a 1.25 mm pitch and 11 contacts in a 3 power, 8 signal arrangement. It utilizes a straight through-hole solder pin termination with a 3.6 mm power contact length. The connector supports current ratings of 2 A for signal and 10 A for power contacts. Constructed with polyamide insulation and gold-plated copper alloy contacts, it operates within a temperature range of -65 °C to +150 °C.

Feature Summary

• Screw-Lok reverse fix mechanism for secure cable retention
• High-reliability design with polarizing key and mating flange
• Vertical through-board mounting for space-efficient PCB integration

Applications

• Industrial control systems requiring high-reliability connections
• Automotive electronics harnesses
• Consumer appliance power distribution boards

Procurement Notes

Verify the specific order code against the official Harwin datasheet to ensure correct contact arrangement and termination style. Confirm that the Screw-Lok feature aligns with assembly requirements. Check RoHS compliance status via manufacturer documentation before final procurement decisions.

Selection Notes

Select this component when a vertical 1.25 mm pitch connector with mixed power and signal contacts is required. Ensure the PCB layout accommodates the 3.6 mm power termination length. Verify that the 10 A power rating meets circuit demands and that the operating temperature range suits the environment.

Part Context

This part belongs to the Gecko-MT family, designed for demanding applications. It complements other Gecko series connectors by offering enhanced mechanical locking. The product line emphasizes durability and precise alignment in compact electronic assemblies.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with Harwin's official compatibility matrix for potential alternatives.
