G125-FV12605L0R

$14.40

Description：CONN RCPT 26POS 0.049 GOLD PCB
Series：Gecko
Mfr：Harwin Inc.
Package：Tape & Reel (TR)

SKU:d60fbb1de88d Category: Headers, Receptacles, Female Sockets Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN RCPT 26POS 0.049 GOLD PCB
Series：Gecko
Mfr：Harwin Inc.
Package：Tape & Reel (TR)
Connector Type：Receptacle
Contact Type：Female Socket
Style：Board to Board or Cable
Number of Positions：26
Number of Positions Loaded：All
Pitch - Mating：0.049" (1.25mm)
Number of Rows：2
Row Spacing - Mating：0.049" (1.25mm)
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Latch Holder
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：8.00µin (0.203µm)
Insulation Color：Green
Insulation Height：0.207" (5.25mm)
Contact Length - Post：0.118" (3.00mm)
Operating Temperature：-65°C ~ 150°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Gold
Mated Stacking Heights：-
Ingress Protection：-
Features：Pick and Place, Polarizing Key
Current Rating (Amps)：2A
Voltage Rating：-

Download product information

G125-FV12605L0R

Overview

The Harwin G125-FV12605L0R is a Gecko-SL series power-to-board connector designed for vertical surface mount applications. It features a 1.25 mm pitch and provides 26 positions arranged in a dual row configuration. The component utilizes female socket contacts with gold plating on copper alloy substrates, rated for 2 A current and 250 V voltage. Designed for operation between -65°C and +150°C, it employs solder pin termination and includes screw fixings with board mount studs for secure attachment.

Feature Summary

Vertical surface mount design with integrated screw fixings
Gold-plated female socket contacts for reliable signal integrity
Dual-row 26-position layout for high-density power routing

Applications

Industrial control systems requiring robust power distribution
Automotive electronics with strict thermal stability needs
Telecommunications infrastructure equipment
Medical device internal power connections

Procurement Notes

Verify the specific suffix 'R' indicates tape and reel packaging when sourcing. Confirm RoHS compliance status through official manufacturer documentation prior to integration. Ensure compatibility with automated pick-and-place equipment specifications. Cross-reference the exact part number against the latest datasheet to confirm terminal type and mounting style match the design requirements.

Selection Notes

Select this model for applications necessitating vertical orientation and mechanical stability via screw fixation. The 1.25 mm pitch allows for compact board layouts while maintaining adequate spacing. Verify that the 2 A current rating aligns with the circuit load requirements. Consider the operating temperature range of -65°C to +150°C for environmental suitability.

Part Context

This component belongs to the Harwin Gecko-SL family, which specializes in high-reliability power connectors. The series is characterized by its modular design and robust mechanical locking mechanisms. The Gecko-SL line supports various mounting styles and contact counts, catering to diverse industrial and automotive power distribution challenges.
