Product Detailed Parameters
- Description：CONN RCPT 50POS 0.049 GOLD PCB
- Series：Gecko SL Reverse Fix
- Mfr：Harwin Inc.
- Package：Tape & Reel (TR)
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：50
- Number of Positions Loaded：All
- Pitch - Mating：0.049" (1.25mm)
- Number of Rows：2
- Row Spacing - Mating：0.049" (1.25mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Screw Lock
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：8.00µin (0.203µm)
- Insulation Color：Green
- Insulation Height：0.207" (5.25mm)
- Contact Length - Post：0.118" (3.00mm)
- Operating Temperature：-65°C ~ 150°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Gold
- Mated Stacking Heights：7.25mm, 7.33mm
- Ingress Protection：-
- Features：Mating Flange, Pick and Place, Polarizing Key
- Current Rating (Amps)：2A
- Voltage Rating：450V
Download product information
Overview
The G125-FV15005F2R is a power-to-board connector from the Harwin Gecko-SL series, designed for vertical through-hole mounting. It features a female socket configuration with 50 positions arranged in a dual-row layout. The component utilizes a 1.25 mm (0.049 inch) pitch and includes gold-plated contacts to ensure reliable signal integrity. This specific part number indicates tape-and-reel packaging suitable for automated pick-and-place assembly processes.
Feature Summary
- Vertical through-hole mounting style for direct board integration
- Gold-plated phosphor bronze contacts for corrosion resistance
- Tape-and-reel packaging optimized for high-volume automation
Applications
- Industrial control systems requiring robust interconnects
- Automotive electronics modules
- Medical device instrumentation
- Telecommunications infrastructure equipment
Procurement Notes
Verify the exact suffix 'R' confirms tape-and-reel packaging rather than bulk supply. Confirm the 50-position count matches the design requirement. Ensure the vertical orientation aligns with the PCB layout constraints. Check RoHS compliance status against current regulatory standards before finalizing procurement orders.
Selection Notes
Select this component when high-density vertical connections are required. The 1.25 mm pitch allows for compact circuit board designs. Gold plating ensures durability in harsh environments. Verify mating connector compatibility within the Gecko-SL ecosystem to maintain mechanical and electrical consistency across the assembly.
Part Context
This connector belongs to the Gecko-SL family, known for its screw-lock latching mechanism. The series offers various configurations including headers, wire housings, and cable assemblies. The G125-FV15005F2R specifically addresses the need for automated assembly of high-pin-count vertical interfaces in space-constrained applications.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with other Harwin Gecko-SL variants only if pin count and pitch match exactly.
