G125-FV20605L0P

Overview

The Harwin G125-FV20605L0P is a Gecko-SL series power-to-board connector designed for vertical through-hole mounting. It features a dual-row female socket configuration with a 1.25 mm pitch and a row spacing of 1.25 mm. The component provides 30 positions (2x15) and utilizes gold-plated beryllium copper contacts housed in green nylon. Rated for 2 A current and 250 V voltage, it operates within a temperature range of -65°C to +150°C.

Feature Summary

• Vertical through-hole solder pin termination for secure PCB attachment
• Gold-plated beryllium copper contacts ensuring reliable conductivity
• Green nylon housing providing thermal stability up to 150°C

Applications

• Industrial control systems requiring high-density power distribution
• Data center infrastructure power modules
• Aerospace electronic assemblies

Procurement Notes

Verify the specific contact count and housing color against the official datasheet before ordering. Confirm that the vertical orientation and through-hole termination method align with the target PCB layout requirements. Ensure compatibility with mating male pins from the same Gecko-SL family.

Selection Notes

Select this component when a compact, high-reliability power connection is needed for vertical board stacking or panel mounting. The 1.25 mm pitch allows for dense packing while maintaining sufficient clearance. Verify that the 2 A per contact rating meets the circuit load requirements.

Part Context

This part belongs to the Harwin Gecko-SL series, which focuses on space-saving solutions for power applications. The series offers various configurations including latch and standard versions, all sharing the distinctive 1.25 mm pitch and robust construction suitable for demanding environments.

Replacement Considerations

No direct substitute part numbers are publicly confirmed for this specific model. Cross-reference only with other Harwin Gecko-SL female connectors sharing identical pitch, row count, and termination style.
