G125-MH10605M3P

$19.70

Description：CONN HDR 1.25MM R/A 6POS
Series：Gecko SL
Mfr：Harwin Inc.
Package：Strip

SKU:ff1cd9b455ae Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HDR 1.25MM R/A 6POS
Series：Gecko SL
Mfr：Harwin Inc.
Package：Strip
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.049" (1.25mm)
Number of Positions：6
Number of Rows：2
Row Spacing - Mating：0.049" (1.25mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Screw Lock
Contact Length - Mating：-
Contact Length - Post：0.130" (3.30mm)
Overall Contact Length：-
Insulation Height：0.209" (5.30mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：8.00µin (0.203µm)
Contact Finish - Post：Gold
Contact Material：Phosphor Bronze
Insulation Material：Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Features：Jackscrews, Mating Flange, Pick and Place, Polarizing Key
Operating Temperature：-65°C ~ 150°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Green
Current Rating (Amps)：2A
Voltage Rating：450V

Download product information

G125-MH10605M3P

Overview

The G125-MH10605M3P is a male plug header from the Harwin Gecko-SL series, designed for through-hole board mounting. It features a 6-position (2x3) configuration with a 1.25 mm pitch and right-angle orientation. The connector utilizes phosphor bronze contacts with gold plating, rated for 2 A current and up to 450 V voltage. Operating temperatures range from -65 °C to +150 °C, supported by UL 94 V-0 flammability ratings.

Feature Summary

Jackscrew locking mechanism ensures secure mating stability
Right-angle design facilitates horizontal wire-to-board connections
Gold-plated phosphor bronze contacts provide reliable signal integrity

Applications

Industrial control systems requiring robust interconnects
Automotive electronics demanding high thermal resistance
Consumer appliances utilizing compact board layouts

Procurement Notes

Verify the specific suffix 'P' against official Harwin documentation to confirm packaging details and material composition. Ensure compatibility with mating sockets in the same Gecko-SL series. Confirm that the right-angle through-hole termination meets your PCB layout requirements before finalizing procurement orders.

Selection Notes

Select this component when a right-angle male header is required for dense 1.25 mm pitch applications. The jack screw feature distinguishes it from standard polarized locks, offering enhanced mechanical retention. Verify that the 3.3 mm termination length fits within your board thickness constraints.

Part Context

This part belongs to the Gecko-SL family, characterized by micro-miniature dimensions and high reliability. The series supports various configurations including vertical and right-angle headers, ensuring consistent performance across diverse electronic assembly needs.
