G125-MH11205L5P

Overview

The G125-MH11205L5P is a Gecko-SL series male header connector manufactured by Harwin. It features a 12-position configuration with a 1.25 mm pitch and right-angle orientation for through-hole mounting. The contacts are gold-plated beryllium copper, rated for 2 A current. The housing is green nylon, designed for vertical mating with female counterparts. This component supports PCB hold-down locking mechanisms.

Feature Summary

• Right-angle through-hole mounting design
• Gold-plated beryllium copper contacts
• PCB hold-down locking mechanism

Applications

• Power to the Board connections
• Industrial control systems
• Telecommunications equipment

Procurement Notes

Verify the specific suffix 'L5P' against the manufacturer's latest datasheet to confirm the tape and reel packaging format and quantity per reel. Ensure the right-angle orientation matches the board layout requirements. Cross-reference the RoHS compliance status directly with the official documentation before procurement.

Selection Notes

Select this part when a right-angle male header with a 1.25 mm pitch is required for space-constrained designs. The Gecko-Latch feature provides secure PCB retention. Verify that the 2 A current rating and temperature range meet the application's electrical and environmental specifications.

Part Context

This component belongs to the Harwin Gecko-SL family of power connectors. It is designed for high-density applications requiring reliable power distribution. The series offers various pin counts and orientations to accommodate different board architectures while maintaining consistent mechanical and electrical performance standards.

Replacement Considerations

Direct substitutes within the same series include G125-MH11605L5P (16 position) or G125-MH10605L5P (6 position). For horizontal straight configurations, consider G125-MH11205L1P. Verify mechanical compatibility and pinout alignment before substitution.
