G125-MS10605M1P

Overview

The Harwin G125-MS10605M1P is a Gecko-SL series power-to-board header connector designed for surface mount technology. It features a 1.25 mm pitch with a 2x3 pin configuration, providing six positions in a dual-row arrangement. The component utilizes male pins made from phosphor bronze with gold plating, rated for 2 A current and 450 V voltage. Constructed with green polyamide insulation, it operates within a temperature range of -65°C to +150°C. The connector includes mounting flanges and supports pick-and-place assembly via tape and reel packaging.

Feature Summary

• Surface mount design with integrated mounting flanges for secure PCB attachment
• Gold-plated phosphor bronze contacts ensuring reliable electrical performance
• High-temperature resistant polyamide insulation suitable for harsh environments

Applications

• Industrial control systems requiring high-reliability interconnects
• Power distribution modules in compact electronic assemblies
• Automotive electronics demanding robust surface mount solutions

Procurement Notes

Verify the specific suffix 'P' indicates tape and reel packaging when sourcing. Confirm RoHS compliance status through official manufacturer documentation prior to integration. Ensure compatibility with automated pick-and-place equipment specifications. Check for any recent product change notifications that may affect material composition or dimensions.

Selection Notes

Select this component for applications necessitating a low-profile, high-density power connection on printed circuit boards. The 1.25 mm pitch allows for compact board layouts while maintaining adequate spacing. Consider the 2 A current rating and 450 V insulation voltage when designing power circuits. The straight orientation and SMT style simplify assembly processes compared to through-hole alternatives.

Part Context

This part belongs to the Harwin Gecko-SL family, known for high-reliability connectors in demanding environments. The G125 designation refers to the 1.25 mm pitch standard within the series. As a male header, it pairs with corresponding female sockets to establish secure power and signal connections. The series emphasizes durability and consistent performance across various industrial sectors.

Replacement Considerations

No direct public substitute part numbers are confirmed for this specific variant.
