Product Detailed Parameters
- Description：CONN HEADER SMD 6POS 1.25MM
- Series：Gecko SL
- Mfr：Harwin Inc.
- Package：Tape & Reel (TR)
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.049" (1.25mm)
- Number of Positions：6
- Number of Rows：2
- Row Spacing - Mating：0.049" (1.25mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Threaded
- Contact Length - Mating：-
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.193" (4.90mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：8.00µin (0.203µm)
- Contact Finish - Post：Gold
- Contact Material：Phosphor Bronze
- Insulation Material：Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
- Features：Mating Flange, Pick and Place, Polarizing Key
- Operating Temperature：-65°C ~ 150°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Green
- Current Rating (Amps)：2A
- Voltage Rating：450V
Download product information
Overview
The G125-MS10605M1R is a Gecko-SL series header connector manufactured by Harwin Inc. It features a 16-position, 2-row configuration with a 1.25 mm pitch and row spacing. Designed for surface mount installation, it utilizes solder pin termination. The contacts are male pins made of phosphor bronze with gold plating. The housing is constructed from halogen-free polyamide (PA4T) in green, rated UL 94 V-0. It supports a current rating of 2 A and operates within a temperature range of -65°C to +150°C.
Feature Summary
- Surface mount design with polarized keying and pick-and-place compatibility
- Four-wall shielding structure for enhanced signal integrity
- Screw-type latching mechanism for secure mating retention
Applications
- Board-to-board interconnections requiring high density
- Automotive electronic control units
- Industrial automation control systems
Procurement Notes
Verify the specific suffix 'M1R' against the official datasheet to confirm the exact contact plating thickness and reel packaging specifications. Ensure the selected variant matches the required PCB footprint and mounting orientation for the target application design.
Selection Notes
Select this component when a compact, shielded surface mount header is required for high-density layouts. The 1.25 mm pitch allows for significant I/O density while maintaining reliable electrical performance. Consider the four-wall shielding if electromagnetic interference protection is necessary for the circuit signals.
Part Context
This part belongs to the Gecko-SL family, characterized by slim profile connectors designed for space-constrained applications. The series emphasizes robust mechanical retention through screw-lock mechanisms and offers various mounting options including surface mount and through-hole configurations across different position counts.
Replacement Considerations
Direct substitutes within the same Gecko-SL series include G125-MS10305L0P and G125-MS11605M1R. Verify that alternative part numbers match the 16-position count, surface mount style, and 1.25 mm pitch requirements before implementation.
