G125-MS11005M3P

Description：CONN HEADER SMD 10POS 1.25MM
Series：Gecko SL Reverse Fix
Mfr：Harwin Inc.
Package：Strip

SKU:a627545efae2 Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER SMD 10POS 1.25MM
Series：Gecko SL Reverse Fix
Mfr：Harwin Inc.
Package：Strip
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.049" (1.25mm)
Number of Positions：10
Number of Rows：2
Row Spacing - Mating：0.049" (1.25mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Screw Lock
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.193" (4.90mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：8.00µin (0.203µm)
Contact Finish - Post：Gold
Contact Material：Phosphor Bronze
Insulation Material：Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Features：Mating Flange, Mounting Flange, Pick and Place
Operating Temperature：-65°C ~ 150°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Green
Current Rating (Amps)：2A
Voltage Rating：450V

Download product information

G125-MS11005M3P

Overview

The Harwin G125-MS11005M3P is a Gecko-SL series power-to-board connector designed for surface mount technology. It features a male pin configuration with a 1.25 mm pitch and a 2x5 position layout, totaling ten contacts. The component utilizes gold-plated phosphor bronze terminals housed in polyamide (PA) insulation. Rated for a continuous current of 2 A and voltages up to 450 V, it supports an operating temperature range from -65 °C to +150 °C. The unit employs a straight SMD solder termination style.

Feature Summary

Surface mount design compatible with automated pick-and-place assembly processes
Jackscrew locking mechanism ensures secure board mounting stability
Gold-plated phosphor bronze contacts provide reliable electrical conductivity

Applications

Industrial control system interconnections
Power distribution modules within electronic enclosures
High-density server backplane connections

Procurement Notes

Verify the specific suffix designation against the manufacturer's official datasheet to confirm exact packaging and terminal specifications. Ensure that the selected variant matches the required surface mount orientation and contact count for your circuit design. Cross-reference the RoHS compliance status with current regulatory requirements before finalizing procurement orders.

Selection Notes

Select this component when a low-profile surface mount solution is required for high-current applications. The 1.25 mm pitch allows for dense circuit board layouts while maintaining adequate spacing. Consider the jack screw feature if vibration resistance is critical for the target environment.

Part Context

This part belongs to the Harwin Gecko-SL family, which specializes in robust power connectors. The series is characterized by its modular design and high reliability standards. It serves as a key interface component for transferring significant power levels between boards and cables in compact form factors.
