G125-MV12005L1P

$6.71

Description：CONN HEADER VERT 20POS 1.25MM
Series：Gecko
Mfr：Harwin Inc.
Package：Strip

SKU:ce2551a347fb Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER VERT 20POS 1.25MM
Series：Gecko
Mfr：Harwin Inc.
Package：Strip
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.049" (1.25mm)
Number of Positions：20
Number of Rows：2
Row Spacing - Mating：0.049" (1.25mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Latch Lock
Contact Length - Mating：-
Contact Length - Post：0.118" (3.00mm)
Overall Contact Length：-
Insulation Height：0.193" (4.90mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：8.00µin (0.203µm)
Contact Finish - Post：-
Contact Material：Phosphor Bronze
Insulation Material：Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Features：Board Lock, Pick and Place
Operating Temperature：-65°C ~ 150°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Green
Current Rating (Amps)：2A per Contact
Voltage Rating：-

Download product information

G125-MV12005L1P

Overview

The Harwin G125-MV12005L1P is a Gecko-Latch male vertical through-board connector with a 1.25mm pitch. It features 20 positions (2x10) and phosphor bronze contacts with gold plating. Rated for 2A current and 450VAC/DC voltage, it operates within -65°C to +150°C. The housing is black polyamide (PA4T), UL94 V-0 rated. Designed for tape and reel packaging, it utilizes screw fixings with board mount studs for secure attachment.
