GBPC1506W-G

Overview

The GBPC1506W-G is a single-phase bridge rectifier manufactured by Comchip Technology, designed for general-purpose power supply applications. It features a glass passivated silicon junction and utilizes the GBPC-W package with wire leads for through-hole mounting. The device supports an average forward current of 15 A and withstands a maximum repetitive peak reverse voltage of 600 V. Key electrical characteristics include a maximum non-repetitive surge current of 300 A at 60 Hz and a low leakage current of 5 µA at rated voltage. The component operates within a temperature range of -55°C to +150°C junction temperature and complies with RoHS standards.

Feature Summary

• Glass passivated chip junctions provide reliable operation and improved stability under thermal stress.
• Integrally molded heatsink in the plastic encapsulation ensures efficient heat dissipation and low thermal resistance.
• Universal terminal design allows for snap-on, wire wrap-around, or printed circuit board mounting configurations.

Applications

• AC to DC conversion in general-purpose power supplies
• Battery charging circuits requiring high surge current capability
• Industrial control systems utilizing through-hole mounting

Procurement Notes

Verify the manufacturer part number against official Comchip Technology documentation to ensure authenticity. Confirm that the specific suffix indicates wire lead configuration as required by the assembly process. Check for RoHS compliance status in the latest datasheet revision. Ensure storage conditions align with semiconductor handling guidelines to prevent moisture sensitivity issues before soldering.

Selection Notes

Select this component when a 15 A continuous current rating and 600 V blocking voltage are required in a through-hole format. Compare thermal resistance values against the available heatsinking options on the target PCB layout. Verify that the package dimensions fit within the designated mechanical constraints of the enclosure. Consider the operating temperature range to ensure reliability under worst-case ambient conditions.

Part Context

This component belongs to the GBPC series of glass passivated bridge rectifiers from Comchip Technology. The series offers various current ratings and voltage options within the same standardized package family. The GBPC1506W-G specifically denotes the 15 A, 600 V variant with wire leads, distinguishing it from tab-mounted versions or different current ratings within the same product line.

Replacement Considerations

Compatible substitutes include the GBPC1506W from Diodes Incorporated and the GBPC1506W from Pan Jit International. These alternatives share identical electrical specifications and pinout configurations. Verify mechanical dimensions and mounting torque requirements before substituting to ensure physical compatibility with existing assemblies.
