GF-210U

Power Line Filter Modules Overview

The KEMET GF-210U is a single-phase power line filter designed for general-purpose EMI/RFI noise suppression. It features a metal box construction with chassis mounting capabilities via threaded studs. The component supports a rated voltage of 250 VAC and handles a current capacity of 10 A. It operates within an ambient temperature range of -20°C to +60°C. The physical dimensions are approximately 70 mm in length, 53 mm in width, and 29 mm in height. This filter utilizes a single-stage topology for effective interference reduction.

Power Line Filter Modules Feature Summary

• Single-phase EMI/RFI noise suppression for power lines
• Metal box enclosure for robust mechanical protection
• Chassis mount design using threaded stud flange
• General-purpose filtering for industrial applications

Power Line Filter Modules Applications

• Industrial machinery power input stages
• Medical equipment electromagnetic compatibility
• Test and measurement instrument power supplies
• General electronic device noise filtering

Power Line Filter Modules Procurement Notes

Verify part status carefully as the GF-210U may be discontinued or obsolete depending on the supplier source. Confirm that the replacement GTX-2100-Y03 meets all electrical and mechanical requirements before procurement. Ensure mounting hardware compatibility with existing chassis designs. Check RoHS compliance status if required by specific project regulations. Validate lead times due to potential availability constraints.

Power Line Filter Modules Selection Notes

Select this component when single-phase noise filtration is required for systems operating at 250 VAC. The 10 A current rating suits moderate power applications. Consider the chassis mount style for fixed installations where space allows. Evaluate the thermal performance within the specified -20°C to +60°C range. Compare against alternative series filters if higher current or different mounting styles are needed.

Power Line Filter Modules Part Context

The GF-210U belongs to KEMET's GF series of specialty EMI/RFI filters. These components are engineered for reliable noise suppression in various electronic environments. The series typically offers standardized form factors for easy integration into control panels and enclosures. KEMET provides comprehensive datasheets detailing insertion loss characteristics and dimensional drawings for design verification.

Power Line Filter Modules Replacement Considerations

The GTX-2100-Y03 is listed as a suggested manufacturer replacement. Verify that the substitute matches the original voltage, current, and mounting specifications. Confirm dimensional compatibility to ensure fit within existing assemblies. Review technical parameters to guarantee equivalent noise suppression performance.
