GF1M1FBSCR

Headers, Male Pins Overview

The GF1M1FBSCR is a Power to the Board connector manufactured by Amphenol Positronic. It features a single row of male pin contacts with a pitch of 7.14 mm. The component utilizes solder cup termination for secure board attachment and supports panel mounting. Constructed with copper alloy contacts featuring gold plating, it ensures reliable conductivity. The housing is made from Diallyl Phthalate (DAP). It operates within a temperature range of -55 C to +125 C and has an insulation resistance of 5 GOhms.

Headers, Male Pins Feature Summary

• Designed for direct power delivery to printed circuit boards
• Utilizes gold-plated copper alloy contacts for corrosion resistance
• Supports robust panel mounting configurations
• Features solder cup termination for stable PCB integration

Headers, Male Pins Applications

• Industrial control systems requiring high current distribution
• Power supply modules connecting to main circuit boards
• Electronic equipment needing reliable panel-mounted power interfaces

Headers, Male Pins Procurement Notes

Verify the specific suffix and contact configuration against the official datasheet before ordering. Confirm that the solder cup termination style matches the target PCB footprint design. Ensure environmental ratings meet operational requirements. Cross-reference manufacturer part numbers to avoid substitution errors. Validate compliance documentation if required for the specific application sector.

Headers, Male Pins Selection Notes

Select this component when a dedicated power-to-board interface is required. Consider the 7.14 mm pitch for spacing constraints. Evaluate the panel mounting style against available chassis space. Assess the thermal performance at the maximum operating temperature limit. Verify compatibility with mating connectors in the system architecture.

Headers, Male Pins Part Context

This part belongs to the Power to the Board series by Amphenol Positronic. It is categorized under power connectors designed for efficient energy transfer. The product line focuses on durable connections for industrial and commercial electronics. It complements other standard density connectors in the manufacturer's portfolio.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult the manufacturer for direct equivalents or updated revisions.
