GFPL3M1FC0H

Headers, Male Pins Overview

The GFPL3M1FC0H is a power-to-board connector manufactured by Amphenol Positronic. It features a male pin contact type with a current rating of 7.5 A and a voltage rating of 300 VAC. The component has 4 positions arranged in a single row with a straight installation angle. Termination is achieved via surface mount soldering. The housing material is Diallyl Phthalate (DAP), and contacts are gold-plated copper alloy. Operating temperature ranges from -55 C to +125 C, with an insulation resistance of 5 GOhms.

Headers, Male Pins Feature Summary

• Surface mount termination for direct PCB integration
• Gold-plated copper alloy contacts for conductivity
• Diallyl Phthalate (DAP) housing material
• Board guide feature for alignment

Headers, Male Pins Applications

• Industrial interconnect systems
• Power distribution networks
• Factory automation equipment
• Instrumentation devices

Headers, Male Pins Procurement Notes

Verify RoHS compliance status as sources indicate non-compliance. Confirm specific packaging quantities and lead times directly with the manufacturer or authorized distributors, as availability data varies across regions. Ensure the ordering suffix matches the required configuration without assuming functional changes based on suffixes alone.

Headers, Male Pins Selection Notes

Select this header for applications requiring surface mount power connections with moderate current capacity. Consider the 300 VAC rating and 7.5 A limit when designing circuits. Verify that the DAP housing material meets environmental requirements for the intended operating temperature range of -55 C to +125 C.

Headers, Male Pins Part Context

This component belongs to the Power to the Board category within Amphenol Positronic's connector portfolio. It serves as a male pin header designed for reliable electrical connections between boards and power sources in industrial and commercial electronic assemblies.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with other Amphenol Positronic headers only if specifications match exactly.

Headers, Male Pins FAQ

What is the contact plating material?

The contacts are gold-plated copper alloy.

Is this connector RoHS compliant?

Sources indicate that the GFPL3M1FC0H is RoHS non-compliant.
