GSTP0230S is listed in the Single Diodes range at ChipApex. The manufacturer field lists Good-Ark Semiconductor. Its product description is DIODE SCHOTTKY 30V 2A SOD323HS. Review the specifications below when checking this part for your BOM.
Single Diodes specifications for GSTP0230S
- Description：DIODE SCHOTTKY 30V 2A SOD323HS
- Series：-
- Mfr：Good-Ark Semiconductor
- Package：Tape & Reel (TR),Cut Tape (CT)
- Technology：Schottky
- Voltage - DC Reverse (Vr) (Max)：30 V
- Current - Average Rectified (Io)：2A
- Voltage - Forward (Vf) (Max) @ If：600 mV @ 2 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：250 µA @ 30 V
- Capacitance @ Vr, F：-
- Mounting Type：Surface Mount
- Package / Case：SC-90, SOD-323F
- Supplier Device Package：SOD-323HS
- Operating Temperature - Junction：-55°C ~ 150°C
- Grade：-
- Qualification：-
Single Diodes datasheet and documents for GSTP0230S
Single Diodes Overview
The GSTP0230S is a surface-mount Schottky rectifier diode manufactured by Good-Ark Semiconductor. It features a maximum repetitive peak reverse voltage of 30 V and an average forward rectified current of 2 A. The device utilizes metal-semiconductor junction technology with epitaxial construction to ensure low forward voltage drop and high switching efficiency. It is housed in the SOD-323HS package, suitable for compact circuit designs.
Single Diodes Feature Summary
- Metal-semiconductor junction construction with guardring for enhanced reliability
- Epitaxial design supporting fast-switching performance
- Low forward voltage drop characteristics for improved power efficiency
Single Diodes Applications
- Power supply circuits
- DC-DC converters
- Reverse polarity protection
Single Diodes Procurement Notes
Verify the specific ordering suffix against the manufacturer's official documentation to confirm exact packaging options such as tape and reel quantities. Ensure the component meets RoHS compliance requirements for your assembly process. Cross-reference the DigiKey part number 1602-GSTP0230S with the original datasheet to validate electrical parameters before procurement.
Single Diodes Selection Notes
Select this component for applications requiring a 30 V blocking voltage and 2 A continuous current capability in a small surface-mount footprint. The SOD-323HS package offers space-saving benefits compared to larger through-hole alternatives. Consider the low forward voltage drop for thermal management in high-efficiency designs.
Single Diodes Part Context
The GSTP0230S belongs to Good-Ark Semiconductor's Schottky Rectifier product line. This series includes various voltage and current ratings designed for general-purpose rectification and switching applications. The device is part of a broader portfolio of discrete semiconductors offered by the manufacturer.
Single Diodes Replacement Considerations
Check for direct pin-compatible substitutes within the same voltage and current ratings from other manufacturers. Verify that alternative Schottky diodes meet the 30 V reverse voltage and 2 A forward current specifications. Ensure the replacement package matches the SOD-323HS form factor for board compatibility.
