GT-20501V

Power Line Filter Modules Overview

The KEMET GT-20501V is a power line filter module designed for chassis mounting. It operates with a rated voltage of 250VAC and supports a current capacity of 5A. The unit functions within a temperature range of -25°C to +55°C. Constructed in a metal box enclosure, this component provides electromagnetic interference suppression for AC power lines. It is classified as a power line filter module intended for industrial or commercial equipment requiring robust noise filtering.

Power Line Filter Modules Feature Summary

• Chassis mount construction for secure installation
• Metal box enclosure design
• Power line filtering capability

Power Line Filter Modules Applications

• Industrial machinery power input stages
• Commercial equipment EMI suppression
• AC power line noise filtering

Power Line Filter Modules Procurement Notes

Verify the current lifecycle status before procurement, as sources indicate scheduled obsolescence. Confirm compatibility with existing chassis mounting hardware and thermal management requirements. Ensure the 5A current rating and 250VAC voltage specifications align with the target circuit design. Check for any specific regulatory certifications required for the end application.

Power Line Filter Modules Selection Notes

Select this model when a pre-assembled, chassis-mountable power line filter is required rather than discrete components. Consider the metal enclosure for shielding effectiveness and mechanical durability. Evaluate the operating temperature range limits against the environmental conditions of the installation site. Verify that the physical dimensions fit the available chassis space.

Power Line Filter Modules Part Context

This component belongs to KEMET's power line filter modules category. It serves as an integrated solution for AC power line filtering, combining filtering elements within a protective metal housing. This format simplifies assembly compared to using individual capacitors and inductors, offering a compact and shielded approach to EMI reduction in power supplies.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Due to the stated scheduled obsolescence, alternative sourcing should be verified through official KEMET channels or authorized distributors for compatible replacement modules.
