GX60-18P(30)

GX60-18P(30) is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Hirose Electric Co Ltd. Its product description is CONN HEADER SMD R/A 18POS 0.4MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for GX60-18P(30)

• Description：CONN HEADER SMD R/A 18POS 0.4MM
• Series：GX
• Mfr：Hirose Electric Co Ltd
• Package：Tape & Reel (TR)
• Connector Type：Receptacle
• Contact Type：Male Pin
• Pitch - Mating：0.016" (0.40mm)
• Number of Positions：18
• Number of Rows：1
• Row Spacing - Mating：-
• Number of Positions Loaded：All
• Style：Board to Cable/Wire
• Shrouding：Shrouded - 4 Wall
• Mounting Type：Surface Mount, Right Angle
• Termination：Solder
• Fastening Type：Push-Pull
• Contact Length - Mating：-
• Contact Length - Post：-
• Overall Contact Length：-
• Insulation Height：0.138" (3.50mm)
• Contact Shape：-
• Contact Finish - Mating：Gold
• Contact Finish Thickness - Mating：-
• Contact Finish - Post：-
• Contact Material：Copper Alloy
• Insulation Material：Liquid Crystal Polymer (LCP)
• Features：Board Lock, Shielded
• Operating Temperature：-30°C ~ 80°C
• Ingress Protection：-
• Material Flammability Rating：UL94 V-0
• Insulation Color：Black
• Current Rating (Amps)：-
• Voltage Rating：30V

Headers, Male Pins datasheet and documents for GX60-18P(30)
