GZC24SFBN-M30

Headers, Male Pins Overview

The GZC24SFBN-M30 is a single-row surface-mount header manufactured by Sullins Connector Solutions. It features 24 positions with a 0.100-inch (2.54mm) pitch and male pin contacts. The connector utilizes gold plating on the contact surfaces to ensure reliable electrical performance. Designed for high-temperature applications, it employs Nylon 9T insulation material, supporting operation in demanding thermal environments while maintaining structural integrity during soldering processes.

Headers, Male Pins Feature Summary

• Utilizes Nylon 9T insulation material for enhanced thermal stability and high-temperature resistance.
• Features gold-plated male pins to ensure durable and reliable electrical connectivity.
• Designed as an unshrouded, breakaway header for flexible board layout integration.

Headers, Male Pins Applications

• High-temperature electronic assemblies requiring robust thermal performance
• Surface-mount circuit board interconnections
• Industrial control systems with elevated operating temperatures

Headers, Male Pins Procurement Notes

Verify the specific suffix M30 against official Sullins documentation to confirm RoHS compliance status and material specifications. Ensure the ordering part number matches the required 24-position configuration and single-row geometry. Cross-reference datasheet revisions to confirm current availability and manufacturing status before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a single-row, surface-mount header with a 2.54mm pitch is required for high-temperature environments. The Nylon 9T insulation offers superior heat resistance compared to standard materials. Confirm that the unshrouded design aligns with the mechanical constraints of the target application and mating connector interface.

Headers, Male Pins Part Context

This component belongs to the Sullins GxCxxSFBN-M30 series of headers. It is categorized under rectangular connectors with male pins. The product line focuses on providing reliable interconnect solutions for various industrial and commercial electronic applications requiring specific mounting and environmental characteristics.

Headers, Male Pins Replacement Considerations

Compatible mating connectors include female headers such as S7055-ND, S7020-ND, and S5653-ND. Verify that any substitute maintains the same 0.100-inch pitch, 24-position count, and surface-mount termination style to ensure mechanical and electrical compatibility.
