H0013FNL

$3.77

Description：PULSE XFMR 1CT:1CT TX 1CT:1CT RX
Series：-
Mfr：Pulse Electronics
Package：Tube

SKU:981d68d5a477 Category: Pulse Transformers Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：PULSE XFMR 1CT:1CT TX 1CT:1CT RX
Series：-
Mfr：Pulse Electronics
Package：Tube
Transformer Type：-
Inductance：350µH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：1CT:1CT Transmitter, 1CT:1CT Receiver
Mounting Type：Surface Mount
Size / Dimension：0.488" L x 0.365" W (12.40mm x 9.27mm)
Height - Seated (Max)：0.073" (1.85mm)
Operating Temperature：0°C ~ 70°C
Grade：-
Qualification：-

Download product information

H0013FNL

Overview

The H0013FNL is a telecom transformer from Pulse Electronics designed for surface mount applications. It supports 10/100Base-TX Ethernet standards with a 1:1 turns ratio and one port configuration. The component features an inductance of 350µH, primary DC resistance of 0.65Ω, and secondary DC resistance of 0.65Ω. Physical dimensions are 12.40mm length by 9.27mm width, with a maximum seated height of 0.073 inches (1.85mm). It utilizes gull-wing SMD terminals.

Feature Summary

Designed for high-performance datacom signal transmission
Supports 10/100Base-TX network protocols
Compact surface mount footprint for automated assembly

Applications

Ethernet network interface cards
Telecommunications equipment
Network switches and routers

Procurement Notes

Verify the specific ordering suffix to ensure correct terminal style and packaging format. Confirm RoHS compliance status through official documentation. Check for AEC-Q200 qualification if automotive application is required. Ensure the datasheet matches the exact part number variant before procurement.

Selection Notes

Select this component for designs requiring 10/100Base-TX isolation with low profile constraints. Verify that the 350µH inductance meets circuit impedance requirements. Ensure PCB land pattern accommodates gull-wing leads. Confirm operating temperature range suitability for the target environment.

Part Context

This component belongs to Pulse Electronics' network transformer portfolio. It serves as a critical isolation element in Ethernet PHY circuits. The product line focuses on miniaturized solutions for modern communication hardware.

Replacement Considerations

Consult official distributor cross-reference tools for verified substitutes. Ensure replacement parts match the 1:1 ratio and 350µH inductance. Verify identical physical dimensions for board compatibility.
