H2B1BC4A1B015L

$1.92

Description：UNICTRON WW20D1 - WIFI, 2400~250
Series：-
Mfr：Unictron Technologies Corporation
Package：Bulk

SKU:4fed81aea804 Category: RF Antennas Brand: Unictron Technologies Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

H2B1BC4A1B015L is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is UNICTRON WW20D1 - WIFI, 2400~250. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for H2B1BC4A1B015L

Description：UNICTRON WW20D1 - WIFI, 2400~250
Series：-
Mfr：Unictron Technologies Corporation
Package：Bulk
RF Family/Standard：WiFi
Frequency Group：UHF (2GHz ~ 3GHz)
Frequency (Center/Band)：2.442GHz
Frequency Range：2.4GHz ~ 2.484GHz
Antenna Type：PCB Trace
Number of Bands：1
VSWR：2
Return Loss：-
Gain：4dBi
Features：Cable - 100mm
Termination：I-PEX MHF1
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Adhesive
Height (Max)：0.020" (0.50mm)
Applications：802.11b/g/n
Power - Max：-

Antennas RF datasheet and documents for H2B1BC4A1B015L

H2B1BC4A1B015L

Antennas RF Overview

The H2B1BC4A1B015L is a PCB printed line RF antenna manufactured by Unictron Technologies Corporation. It operates within the 2.4GHz to 2.484GHz frequency range, supporting IEEE 802.11b/g/n standards at 2.442GHz. The component features a gain of 4dBi and utilizes an I-PEX MHF1 connector interface. Its physical dimensions are 20.0mm x 7.0mm x 0.5mm, designed for adhesive mounting on printed circuit boards.

Antennas RF Feature Summary

Supports 2.4GHz ISM band operations including 802.11b/g/n protocols
Utilizes I-PEX MHF1 connector for reliable signal transmission
Compact low-profile design suitable for space-constrained applications

Antennas RF Applications

Wireless LAN modules
Bluetooth devices
IoT sensor nodes

Antennas RF Procurement Notes

Verify the specific ordering suffix matches the required configuration. Confirm the connector type is I-PEX MHF1. Ensure the operating frequency aligns with 2.4GHz to 2.484GHz requirements. Check that the manufacturer is Unictron Technologies Corporation. Validate the physical dimensions against board layout constraints.

Antennas RF Selection Notes

Select this component when a compact PCB antenna is required for 2.4GHz wireless communication. The I-PEX MHF1 interface ensures compatibility with standard RF connectors. The 4dBi gain provides adequate performance for short-range data transmission. Consider the adhesive mounting method for secure installation.

Antennas RF Part Context

This part belongs to Unictron's WiFi PCB antenna series, specifically the WW20D1 family. It is designed for integration into consumer electronics requiring wireless connectivity. The manufacturer specializes in antennas and piezoelectric ceramic elements.
