H2P13648110100

$31.23

Description：PB50DMS (49.5X49.5X8MM); GPS(L1+
Series：-
Mfr：Unictron Technologies Corporation
Package：Bag

SKU:5a9667780456 Category: RF Antennas Brand: Unictron Technologies Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

H2P13648110100 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is PB50DMS (49.5X49.5X8MM); GPS(L1+. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for H2P13648110100

Description：PB50DMS (49.5X49.5X8MM); GPS(L1+
Series：-
Mfr：Unictron Technologies Corporation
Package：Bag
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.176GHz, 1.575GHz
Frequency Range：-
Antenna Type：Ceramic Patch
Number of Bands：1
VSWR：-
Return Loss：-10dB
Gain：6.1dBi, 4.5dBi
Features：-
Termination：-
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Adhesive
Height (Max)：0.406" (10.30mm)
Applications：BeiDou, Galileo, GLONASS, GNSS, GPS, QZSS
Power - Max：-
