H2PE366R110100

$11.23

Description：PB18DRS (18X18X5MM); GPS(L1+L5)/
Series：-
Mfr：Unictron Technologies Corporation
Package：Bag

SKU:b78239991f1c Category: RF Antennas Brand: Unictron Technologies Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

H2PE366R110100 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is PB18DRS (18X18X5MM); GPS(L1+L5)/. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for H2PE366R110100

Description：PB18DRS (18X18X5MM); GPS(L1+L5)/
Series：-
Mfr：Unictron Technologies Corporation
Package：Bag
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.1765GHz, 1.57542GHz, 1.602GHz
Frequency Range：-
Antenna Type：Ceramic Patch
Number of Bands：3
VSWR：-
Return Loss：-10dB
Gain：-0.8dBi, 3.1dBi, 2dBi
Features：-
Termination：Pin
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Adhesive
Height (Max)：0.197" (5.00mm)
Applications：Galileo, GLONASS, GPS
Power - Max：-

Antennas RF datasheet and documents for H2PE366R110100

H2PE366R110100

Antennas RF Overview

The H2PE366R110100 is a ceramic patch RF antenna manufactured by Unictron Technologies Corporation, designed for navigation applications including Galileo, GLONASS, and GPS. It supports three frequency bands: 1.1765GHz, 1.57542GHz, and 1.602GHz. The component features gains of -0.8dBi, 3.1dBi, and 2dBi respectively, with a maximum height of 5.00mm (0.197 inches). It utilizes pin termination and adhesive mounting. The unit operates within the UHF band (1GHz ~ 2GHz) and maintains a return loss of -10dB.

Antennas RF Feature Summary

Supports multi-constellation navigation signals including Galileo, GLONASS, and GPS
Utilizes ceramic patch construction for structural integrity
Designed for adhesive installation via pin termination

Antennas RF Applications

Galileo satellite navigation systems
GLONASS positioning devices
GPS receiver modules

Antennas RF Procurement Notes

Verify the specific manufacturer part number H2PE366R110100 against official Unictron documentation to confirm compatibility with target navigation standards. Ensure that the adhesive mounting method and pin termination align with the mechanical design of the host device. Cross-reference the frequency specifications to guarantee signal integrity for the intended application environment.

Antennas RF Selection Notes

Select this component when multi-band support for Galileo, GLONASS, and GPS is required in a compact form factor. The ceramic patch type offers stability suitable for navigation receivers. Consider the adhesive mounting constraint and physical dimensions during PCB layout. Verify that the gain characteristics meet the system's link budget requirements for each supported frequency band.

Antennas RF Part Context

This component belongs to the Unictron Technologies Corporation portfolio of RF antennas. It is categorized under navigation-grade ceramic patch antennas. The product is currently listed as active. It serves as a specialized solution for integrating global navigation satellite system capabilities into electronic devices requiring precise positioning data.
