H2U36G1L1B0100

$0.95

Description：WIFI/BLUETOOTH CHIP ANTENNA(8.0X
Series：-
Mfr：Unictron Technologies Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:4a3b08764dc4 Category: RF Antennas Brand: Unictron Technologies Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

H2U36G1L1B0100 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is WIFI/BLUETOOTH CHIP ANTENNA(8.0X. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for H2U36G1L1B0100

Description：WIFI/BLUETOOTH CHIP ANTENNA(8.0X
Series：-
Mfr：Unictron Technologies Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
RF Family/Standard：General ISM
Frequency Group：UHF (2GHz ~ 3GHz)
Frequency (Center/Band)：2.45GHz
Frequency Range：2.4GHz ~ 2.5GHz
Antenna Type：Chip
Number of Bands：1
VSWR：2
Return Loss：-
Gain：0.5dBi
Features：-
Termination：Solder
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.020" (0.50mm)
Applications：General Purpose
Power - Max：-

Antennas RF datasheet and documents for H2U36G1L1B0100

H2U36G1L1B0100

Antennas RF Overview

The H2U36G1L1B0100 is a general-purpose chip RF antenna manufactured by Unictron Technologies Corporation. It operates within the 2.4GHz to 2.5GHz frequency range, centered at 2.45GHz. The component features a surface mount installation type with solder termination and a maximum height of 0.020 inches (0.50mm). It provides a typical gain of 0.5dBi and maintains a VSWR of 2. Designed for UHF applications, it supports standard 50-ohm impedance and handles a maximum input power of 2W.

Antennas RF Feature Summary

Surface mount chip design for compact integration
Dual-band support for Wi-Fi and Bluetooth ISM applications
Low profile construction suitable for space-constrained devices

Antennas RF Applications

Wi-Fi module integration
Bluetooth peripheral connectivity
General purpose ISM band communication devices

Antennas RF Procurement Notes

Verify the specific package variant required, as the part number may be available in tape and reel or cut tape formats depending on distributor configuration. Confirm that the solder termination method aligns with your PCB assembly process capabilities. Ensure the operating temperature range meets your environmental requirements before finalizing the procurement order.

Antennas RF Selection Notes

Select this component when a low-profile solution is required for dual-band 2.4GHz wireless applications. The chip antenna format offers consistent performance without the variability of external wire antennas. Consider the 0.50mm height constraint if vertical clearance is limited. Verify ground plane requirements against the manufacturer's datasheet to ensure optimal radiation efficiency.

Antennas RF Part Context

This model belongs to Unictron's general-purpose chip antenna series designed for short-range wireless communications. It serves as a compact alternative to larger ceramic or monopole antennas. The product line focuses on providing reliable RF performance for consumer electronics and IoT devices requiring standardized ISM band operation.
