H2U66J1K2C0100

Antennas RF Overview

The H2U66J1K2C0100 is a chip antenna manufactured by Unictron Technologies Corporation, designed for the UHF frequency group (300MHz to 1GHz). It operates within the General ISM RF family and supports a single band centered around 928MHz. The component utilizes a PowerDI EP package with three pins and employs surface mount solder termination. Key electrical specifications include a gain of -0.98dBi and a Voltage Standing Wave Ratio (VSWR) of 2. This evaluation board variant integrates the AA066 antenna element.

Antennas RF Feature Summary

• Supports General ISM applications in the UHF frequency range
• Utilizes surface mount solder termination for PCB integration
• Designed as a compact chip antenna solution

Antennas RF Applications

• ISM band wireless communication systems
• UHF RFID reader modules
• Industrial monitoring devices requiring 900MHz connectivity

Antennas RF Procurement Notes

Verify the specific package type and pin configuration against the official datasheet before integration. Confirm that the operating frequency aligns with regional ISM regulations. Ensure the VSWR requirements of the host system are compatible with the component's specified performance metrics.

Antennas RF Selection Notes

Select this component for designs requiring a low-profile UHF antenna solution. Consider the -0.98dBi gain when calculating link budgets. Verify compatibility with the target PCB material and trace impedance matching networks to maintain the specified VSWR performance.

Antennas RF Part Context

This part belongs to the Unictron Technologies Corporation antenna portfolio, specifically categorized under RF and wireless components. It serves as an evaluation or reference design variant for the AA066 antenna technology, facilitating development for UHF ISM applications.

Antennas RF Replacement Considerations

Direct substitutes may include other Unictron chip antennas in the same UHF ISM category. Cross-reference the physical dimensions and pinout with alternative models from the manufacturer to ensure mechanical fit.
