H2UA6K2K1N0200 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is GSM 3G CHIP 824-960 1710-2170 MH. Review the specifications below when checking this part for your BOM.
Antennas RF specifications for H2UA6K2K1N0200
- Description：GSM 3G CHIP 824-960 1710-2170 MH
- Series：-
- Mfr：Unictron Technologies Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- RF Family/Standard：Cellular
- Frequency Group：UHF (300MHz ~ 1GHz), UHF (1GHz ~ 2GHz)
- Frequency (Center/Band)：892MHz, 1.94GHz
- Frequency Range：824MHz ~ 960MHz, 1.71GHz ~ 2.17GHz
- Antenna Type：Chip
- Number of Bands：2
- VSWR：3
- Return Loss：-
- Gain：1.1dBi, 2.4dBi
- Features：-
- Termination：Solder
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Height (Max)：0.126" (3.20mm)
- Applications：3G, GSM
- Power - Max：2 W
Antennas RF datasheet and documents for H2UA6K2K1N0200
Antennas RF Overview
The H2UA6K2K1N0200 is a chip antenna manufactured by Unictron Technologies Corporation, designed for dual-band operation at 960MHz and 2170MHz. It features a gain of 2.4dBi and utilizes a 10-pin configuration. The component is intended for surface-mount installation with solder termination. This RF antenna supports applications requiring wideband coverage across the specified frequency ranges.
Antennas RF Feature Summary
- Supports dual-band functionality covering 960MHz and 2170MHz frequencies
- Utilizes a 10-pin chip design for compact integration
- Provides 2.4dBi gain for efficient signal transmission
Antennas RF Applications
- Wideband communication systems
- RF transceiver modules
- IoT devices requiring multi-frequency support
Antennas RF Procurement Notes
Verify the specific pinout configuration and soldering requirements against the official datasheet before implementation. Ensure compatibility with the target PCB layout for the 10-pin package. Confirm that the operating temperature range meets system specifications. Cross-reference the RoHS compliance status with regulatory requirements for the destination market.
Antennas RF Selection Notes
Select this component when dual-band performance at 960MHz and 2170MHz is required in a small form factor. The 2.4dBi gain offers a balance between size and efficiency. Consider the 10-pin footprint constraints during PCB design. Evaluate thermal management needs for surface-mount applications in enclosed environments.
Antennas RF Part Context
This part belongs to Unictron's chip antenna series, focusing on compact RF solutions. It complements other Unictron products like the H2U1631S1A0200 GPS antenna and H2UJ4U1H2Q0100 quad-band GNSS antenna. The product line emphasizes innovative technologies for wireless connectivity and positioning applications.
