H2UB4K1H1B0100

$0.37

Description：WIFI/BT 2400-2500MHZ TELA CERAMI
Series：-
Mfr：Unictron Technologies Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e76b12bbf446 Category: RF Antennas Brand: Unictron Technologies Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

H2UB4K1H1B0100 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is WIFI/BT 2400-2500MHZ TELA CERAMI. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for H2UB4K1H1B0100

Description：WIFI/BT 2400-2500MHZ TELA CERAMI
Series：-
Mfr：Unictron Technologies Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
RF Family/Standard：802.15.4, Bluetooth, General ISM, WiFi
Frequency Group：UHF (2GHz ~ 3GHz)
Frequency (Center/Band)：2.45GHz
Frequency Range：2.4GHz ~ 2.5GHz
Antenna Type：Chip
Number of Bands：1
VSWR：2.5
Return Loss：-
Gain：-0.3dBi
Features：-
Termination：Solder
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.012" (0.30mm)
Applications：802.11b/g/n, Bluetooth, ISM, Wi-Fi, Zigbee™
Power - Max：2 W

Antennas RF datasheet and documents for H2UB4K1H1B0100

H2UB4K1H1B0100

Antennas RF Overview

The H2UB4K1H1B0100 is a ceramic chip RF antenna manufactured by Unictron Technologies Corporation, designed for the 2.4GHz to 2.5GHz frequency range with a center frequency of 2.45GHz. It provides -0.3dBi gain and supports a maximum power of 2W. The component features a VSWR of 2.5 and utilizes surface mount soldering termination. With a maximum height of 0.012 inches (0.30mm), it complies with RoHS3 standards and holds an MSL rating of 1.

Antennas RF Feature Summary

Compact surface-mount ceramic chip construction suitable for space-constrained designs
Optimized performance across 802.11b/g/n, Bluetooth, ISM, Wi-Fi, and Zigbee protocols
Compliant with RoHS3 environmental regulations

Antennas RF Applications

Wi-Fi modules supporting 802.11b/g/n standards
Bluetooth wireless communication devices
Zigbee™ networking equipment
General ISM band applications

Antennas RF Procurement Notes

Verify that the specific order matches the manufacturer part number H2UB4K1H1B0100 from Unictron Technologies Corporation. Confirm the package type corresponds to tape and reel specifications as indicated in official documentation. Ensure compliance requirements align with project needs, specifically checking RoHS3 status and MSL level 1 handling precautions during assembly processes.

Antennas RF Selection Notes

Select this component when a low-profile ceramic antenna is required for 2.4GHz wireless applications. The -0.3dBi gain and 2W power handling define its operational limits. Consider the 0.30mm height constraint for PCB stacking clearance. Verify impedance matching networks are compatible with the specified VSWR characteristics for optimal signal transmission in target device architectures.

Antennas RF Part Context

This model belongs to the H2UB4 series of ceramic antennas produced by Unictron Technologies Corporation. It is categorized under RF antennas within the UHF frequency group. The product is currently active and serves as a standard solution for compact wireless connectivity implementations requiring reliable performance in the 2.4GHz spectrum.
