H2UB6D1K1B0100

Antennas RF Overview

The H2UB6D1K1B0100 is a ceramic chip RF antenna manufactured by Unictron Technologies Corporation, designed for the 2.4GHz ISM band. It operates within a frequency range of 2.4GHz to 2.5GHz with a center frequency of 2.45GHz. The component features a surface mount package with solder termination and measures 3.0 x 3.0 x 3.3mm. It supports standards including 802.11b/g/n, Bluetooth, Wi-Fi, and Zigbee.

Antennas RF Feature Summary

• Supports multiple wireless protocols including Wi-Fi, Bluetooth, and Zigbee
• Compact ceramic chip construction for space-constrained designs
• Surface mount solder termination for automated assembly

Antennas RF Applications

• Wi-Fi enabled devices
• Bluetooth peripherals
• Zigbee sensor networks
• ISM band industrial applications

Antennas RF Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to ensure correct packaging and tolerance specifications. Confirm that the surface mount footprint matches the PCB layout requirements before finalizing procurement orders.

Antennas RF Selection Notes

Select this component for applications requiring a low-profile antenna solution in the 2.4GHz spectrum. Ensure the design accommodates the specified surface mount dimensions and soldering thermal profile compatible with ceramic RF components.

Antennas RF Part Context

This part belongs to Unictron's line of ceramic chip antennas intended for short-range wireless communication. It serves as a passive radiating element for embedded systems requiring reliable performance in the unlicensed ISM band without external matching networks.

Antennas RF Replacement Considerations

Check for direct substitutes from Unictron or other manufacturers offering identical 2.4GHz ceramic chip specifications. Verify mechanical footprint compatibility and electrical performance metrics before substituting.
