H2UC4W1H2D0300 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is DUAL BAND WIFI+GNSS 1560-1610 24. Review the specifications below when checking this part for your BOM.
Antennas RF specifications for H2UC4W1H2D0300
- Description：DUAL BAND WIFI+GNSS 1560-1610 24
- Series：-
- Mfr：Unictron Technologies Corporation
- Package：Tape & Reel (TR),Cut Tape (CT)
- RF Family/Standard：Navigation, WiFi
- Frequency Group：Wide Band
- Frequency (Center/Band)：1.575GHz, 2.45GHz, 5.5GHz
- Frequency Range：1.575GHz, 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz
- Antenna Type：Chip
- Number of Bands：3
- VSWR：2, 3
- Return Loss：-
- Gain：0.4dBi, 1.5dBi, 2.3dBi
- Features：-
- Termination：Solder
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Height (Max)：0.020" (0.50mm)
- Applications：802.11a/b/g/n/ac, GPS, Wi-Fi
- Power - Max：2 W
Antennas RF datasheet and documents for H2UC4W1H2D0300
Antennas RF Overview
The H2UC4W1H2D0300 is a dual-band GNSS and WiFi ceramic chip antenna manufactured by Unictron Technologies Corporation. It supports the GPS L1 band at 1560-1610 MHz and the WiFi 2.4 GHz band. The component is designed for surface-mount installation, offering integrated reception capabilities for global navigation satellite systems alongside wireless local area network connectivity in a compact form factor.
Antennas RF Feature Summary
- Dual-band operation supporting both GNSS and WiFi frequencies
- Ceramic chip construction for robust performance
- Surface-mount device (SMD) package design
Antennas RF Applications
- GPS L1 positioning modules
- WiFi-enabled navigation devices
- Integrated location tracking hardware
Antennas RF Procurement Notes
Verify the specific frequency range requirements against the official datasheet to ensure compatibility with the 1560-1610 MHz GNSS band and 2.4 GHz WiFi band. Confirm that the surface-mount footprint matches the PCB layout specifications provided by Unicron Technologies Corporation before finalizing procurement orders.
Antennas RF Selection Notes
Select this component when a single antenna solution is required for simultaneous GNSS and WiFi signal reception. Ensure the application environment accommodates the ceramic material properties and that the surface-mount assembly process aligns with the manufacturer's recommended soldering profiles for reliable electrical connections.
Antennas RF Part Context
This part belongs to Unicron Technologies Corporation's portfolio of RF antennas and antenna modules. The company specializes in providing solutions for high-precision positioning and wireless communication applications, utilizing advanced ceramic and piezoelectric technologies to deliver compact and efficient antenna components for modern electronic devices.
Antennas RF Replacement Considerations
Consult the official Unicron Technologies Corporation documentation for verified substitute part numbers. Cross-reference pin configurations and electrical characteristics carefully to ensure functional equivalence without modifying the existing circuit design or mechanical constraints.
