H2UE3P2D2G0100

$3.56

Description：LTE/4G FULL BAND 698-960 1710-26
Series：-
Mfr：Unictron Technologies Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e29740886a2b Category: RF Antennas Brand: Unictron Technologies Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

H2UE3P2D2G0100 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is LTE/4G FULL BAND 698-960 1710-26. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for H2UE3P2D2G0100

Description：LTE/4G FULL BAND 698-960 1710-26
Series：-
Mfr：Unictron Technologies Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
RF Family/Standard：Cellular
Frequency Group：Wide Band
Frequency (Center/Band)：748MHz, 892MHz, 1.94GHz, 2.35GHz, 2.59GHz
Frequency Range：698MHz ~ 798MHz, 824MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.4GHz, 2.49GHz ~ 2.69GHz
Antenna Type：Chip
Number of Bands：5
VSWR：3, 3.5
Return Loss：-
Gain：0.5dBi, 1.3dBi, 2.4dBi, 2.6dBi, 3dBi
Features：-
Termination：Solder
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.157" (4.00mm)
Applications：2G, 3G, CDMA, DCS, EDGE, GPRS, GSM, HSDPA, LTE, PCS, UMTS, WCDMA
Power - Max：2 W

Antennas RF datasheet and documents for H2UE3P2D2G0100

H2UE3P2D2G0100

Antennas RF Overview

The H2UE3P2D2G0100 is a surface-mount ceramic RF antenna designed for full-band LTE and 4G mobile communications. It operates across the frequency ranges of 698MHz to 960MHz and 1710MHz to 2690MHz, supporting multiple cellular standards including GSM, GPRS, EDGE, UMTS, HSDPA, and LTE. The component features a compact form factor with a maximum height of 4.00mm (0.157 inches) and utilizes solder termination for PCB integration. It is engineered for high-performance signal reception in modern wireless devices requiring broad spectral coverage.

Antennas RF Feature Summary

Supports comprehensive multi-standard cellular communication protocols
Enables wideband operation across primary global LTE and 4G spectrum allocations
Utilizes robust ceramic construction for reliable surface-mount installation

Antennas RF Applications

LTE/4G mobile handsets and smartphones
Wireless routers and broadband modems
IoT modules requiring full-band cellular connectivity
Portable GPS/navigation devices with integrated cellular data

Antennas RF Procurement Notes

Verify the specific datasheet version from Unictron Technologies Corporation to confirm mechanical dimensions and electrical performance characteristics prior to procurement. Ensure compatibility with the target PCB layout and soldering profile. Cross-reference the manufacturer part number against authorized distributor listings to guarantee authenticity and traceability of the components.

Antennas RF Selection Notes

Select this antenna when the design requires support for both lower band (698-960MHz) and upper band (1710-2690MHz) cellular frequencies within a single compact package. Consider the 4.00mm height constraint for thin-profile device enclosures. Validate that the application environment does not require specialized shielding beyond standard ceramic antenna capabilities.

Antennas RF Part Context

This component belongs to the Unictron Technologies Corporation portfolio of ceramic chip antennas. It is specifically categorized under RF antennas for mobile communication applications. The part is distinct from GNSS-only or Wi-Fi/BT combo antennas, focusing exclusively on cellular voice and data transmission bands.
