H2UJ4U1H2Q0100

$2.83

Description：UNICTRON CB501F - QUAD BAND GNSS
Series：-
Mfr：Unictron Technologies Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:797df7005b2b Category: RF Antennas Brand: Unictron Technologies Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

H2UJ4U1H2Q0100 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Unictron Technologies Corporation. Its product description is UNICTRON CB501F - QUAD BAND GNSS. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for H2UJ4U1H2Q0100

Description：UNICTRON CB501F - QUAD BAND GNSS
Series：-
Mfr：Unictron Technologies Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.176GHz, 1.2276GHz, 1.2787GHz, 1.575GHz
Frequency Range：-
Antenna Type：Chip
Number of Bands：4
VSWR：2
Return Loss：-
Gain：-
Features：-
Termination：Solder
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.020" (0.50mm)
Applications：Beidou, Galileo, GLONASS, GNSS, GPS
Power - Max：2 W

Antennas RF datasheet and documents for H2UJ4U1H2Q0100

H2UJ4U1H2Q0100

Antennas RF Overview

The H2UJ4U1H2Q0100 is a quad-band GNSS chip antenna manufactured by Unictron Technologies Corporation. It supports frequencies of 1.176GHz, 1.2276GHz, 1.2787GHz, and 1.575GHz for Beidou, Galileo, GLONASS, and GPS systems. The component features a VSWR of 2, maximum power handling of 2 W, and a maximum height of 0.020 inches (0.50mm). It utilizes solder termination and surface mount installation.

Antennas RF Feature Summary

Supports four distinct GNSS frequency bands for global positioning compatibility
Low profile ceramic construction suitable for space-constrained designs
Surface mount package with solder termination for automated assembly

Antennas RF Applications

Beidou navigation systems
Galileo satellite navigation
GLONASS positioning devices
GPS receivers
General GNSS modules

Antennas RF Procurement Notes

Verify the specific manufacturer part number against official Unictron documentation to ensure authenticity. Confirm that the received components match the RoHS3 compliance status and MSL rating specified in the datasheet. Check for physical integrity of the ceramic body and solder pads prior to integration into the PCB layout.

Antennas RF Selection Notes

Select this component when multi-constellation support including Beidou, Galileo, GLONASS, and GPS is required. The low profile design aids in minimizing overall device thickness. Ensure the application environment accommodates the specified maximum power handling and operating frequency range without interference.

Antennas RF Part Context

This model belongs to the CB501F series of GNSS antennas from Unictron Technologies Corporation. It is designed as a ceramic chip antenna optimized for high-precision positioning applications. The product line focuses on providing stable performance across multiple global navigation satellite systems within a compact form factor.
