H5015NLT
Search Product
Search Post
— IC芯片 | 连接器 | 传感器 | 被动器件 —
Consult the customer manager about the wholesale price.
consultation hotline：86-132-6715-2157
email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.
Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.
Product Detailed Parameters
- Description：TRANSFORMER MODULE GIGABIT 1PORT
- Series：-
- Mfr：Pulse Electronics
- Package：Tape & Reel (TR),Cut Tape (CT)
- Transformer Type：Isolation and Data Interface (Encapsulated)
- Inductance：-
- ET (Volt-Time)：-
- Turns Ratio - Primary:Secondary：1CT:1CT
- Mounting Type：Surface Mount
- Size / Dimension：0.697" L x 0.480" W (17.70mm x 12.20mm)
- Height - Seated (Max)：0.185" (4.70mm)
- Operating Temperature：0°C ~ 70°C
- Grade：-
- Qualification：-
Download product information
Overview
The H5015NLT is a surface-mount LAN transformer module designed for Gigabit Ethernet applications. It supports 10/100/1000 Base-T standards with a single port configuration and non-PoE operation. The component features an inductance of 350 µH, a turns ratio of 1CT:1CT for both transmitter and receiver circuits, and an insulation voltage of 1.5 kV. Operating within a temperature range of 0°C to +70°C, it utilizes SMD/SMT termination and operates across a frequency range of 1 MHz to 100 MHz.
Feature Summary
- Supports 10/100/1000 Base-T Gigabit Ethernet data transmission standards
- Provides galvanic isolation with 1.5 kV insulation voltage rating
- Features integrated common mode choke functionality for signal integrity
Applications
- Gigabit Ethernet network interface cards
- Ethernet switch ports
- Computer motherboard LAN connections
Procurement Notes
Verify the specific package variant (NL vs FNL) against schematic requirements, as dimensions differ significantly. Confirm RoHS3 compliance status through official manufacturer documentation prior to integration. Ensure supply chain sources provide valid traceability records for industrial or commercial deployment contexts.
Selection Notes
Select this component for single-port Gigabit Ethernet designs requiring non-PoE solutions. Compare physical footprint constraints against alternative models like H5014FNLT if space is limited. Validate thermal performance within the specified 0°C to +70°C operating range for the target environment.
Part Context
This part belongs to Pulse Electronics' LAN transformer portfolio, specifically engineered for high-speed data communication interfaces. It serves as a critical isolation component between the PHY chip and the RJ45 connector, ensuring signal integrity and electrical safety in network hardware implementations.
Replacement Considerations
H5014FNLT is listed as a parameter-equivalent substitute by distributors, though physical dimensions may vary. Verify pinout compatibility and mechanical fit before substitution.
