H6200NL

Overview

The H6200NL is a dual-port LAN transformer module manufactured by Pulse Electronics, designed for 1000 Base-T PoE applications. It features surface mount (SMD) termination and operates within a frequency range of 1 MHz to 125 MHz. The component provides an inductance of 350 µH and supports a primary coil impedance of 1 Ohm with a secondary coil impedance of 1 Ohm. It offers 1.5 kV isolation voltage and functions between 0°C and +70°C. The physical dimensions are 27.94 mm in length, 10.92 mm in width, and 7.54 mm in height.

Feature Summary

• Supports Power over Ethernet (PoE) functionality for dual-port Gigabit Ethernet connections
• Provides electrical isolation with a 1.5 kVrms insulation voltage rating
• Designed for surface mount assembly on printed circuit boards

Applications

• 1000 Base-T PoE network interfaces
• Dual-port Gigabit Ethernet transceivers
• LAN modules requiring signal transformation

Procurement Notes

Verify the specific ordering suffix against official documentation to confirm exact packaging and variant specifications. Ensure compatibility with the target PCB footprint and thermal requirements. Confirm RoHS compliance status through the manufacturer's current datasheet before finalizing procurement decisions.

Selection Notes

Select this component for designs requiring dual-port Gigabit Ethernet support with integrated PoE capabilities. Consider the SMD package dimensions and operating temperature range relative to the system environment. Verify that the 350 µH inductance and 1 Ohm impedance values align with the specific PHY controller requirements.

Part Context

This part belongs to the Pulse Electronics LAN Transformers category, specifically engineered for high-speed data transmission networks. It serves as a critical interface component between the Ethernet PHY and the physical medium, ensuring signal integrity and isolation in modern networking hardware.

Replacement Considerations

Consult official substitution lists for verified alternatives. Cross-reference pinouts and electrical parameters carefully when considering equivalent components from other manufacturers.
