HA65A-25154R7LF

$5.22

Description：FIXED IND 4.7UH 2.6 MOHM SMD
Series：HA65A
Mfr：TT Electronics/BI Magnetics
Package：Tray

SKU:156ff7e3b70e Category: Fixed Inductors Brand: TT Electronics/BI Magnetics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：FIXED IND 4.7UH 2.6 MOHM SMD
Series：HA65A
Mfr：TT Electronics/BI Magnetics
Package：Tray
Type：Wirewound
Material - Core：-
Inductance：4.7 µH
Tolerance：±10%
Current Rating (Amps)：-
Current - Saturation (Isat)：61A
Shielding：Unshielded
DC Resistance (DCR)：2.6mOhm Max
Q @ Freq：-
Frequency - Self Resonant：21MHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 155°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：1.043" L x 1.043" W (26.50mm x 26.50mm)
Height - Seated (Max)：0.610" (15.50mm)
Features：-

Download product information

HA65A-25154R7LF

Overview

The HA65A-25154R7LF is a surface mount power inductor from the HA65A series, manufactured by TT Electronics/BI Magnetics. It features an unshielded wirewound construction with a nominal inductance of 4.7 µH and a tolerance of ±10%. The component has a maximum DC resistance (DCR) of 2.6 mΩ and a saturation current rating of 61 A. It is designed for high-current applications requiring robust thermal performance.

Feature Summary

Unshielded wirewound design suitable for high-current power supply circuits
High saturation current capability of 61 A for stable operation under load
Low DC resistance of 2.6 mΩ to minimize conduction losses

Applications

Power supply output filtering
DC-DC converter input/output stages
High-current chokes in industrial electronics

Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm that the specific suffix matches the required electrical parameters. Check for end-of-life status as the HA65A series has been discontinued due to material discontinuance. Ensure storage conditions comply with manufacturer guidelines to prevent degradation before assembly.

Selection Notes

Select this component when high saturation current and low DCR are critical for efficiency. Consider the unshielded nature regarding electromagnetic interference (EMI) requirements. Evaluate footprint compatibility with PCB layout constraints. Compare against alternative series if the HA65A is no longer available, ensuring similar current ratings and inductance values.

Part Context

The HA65A series represents a line of surface mount power inductors designed for demanding power management applications. This specific model, HA65A-25154R7LF, falls within the range of fixed inductors offering high current handling. The series is characterized by its wirewound technology and unshielded form factor, prioritizing current capacity over magnetic shielding.

Replacement Considerations

The HA65A series has been officially discontinued. No direct substitute part numbers are confirmed in public documentation. Designers must evaluate alternative high-current SMD inductors from other manufacturers or different product lines that meet the 4.7 µH, 61 A, and 2.6 mΩ specifications.
