HB160826G040

Overview

The Hoffman HB160826G040 is a Genesis series top-mount indoor enclosure air conditioner designed for NEMA 12 applications. It provides 8,000 Btu/hr cooling capacity using refrigerant technology. The unit operates on 230 VAC single-phase power at 50/60 Hz with a maximum current rating of 9.3 A. Constructed from gray steel, it features mechanical thermostat control and functions within an ambient temperature range of 50 to 125 degrees F.

Feature Summary

• Top-mount design for direct installation on compatible enclosures
• Sealed refrigerant cooling system for dust-tight performance
• Mechanical thermostat for reliable temperature regulation

Applications

• Cooling electrical enclosures in industrial environments
• Temperature control for NEMA 12 rated equipment housings
• Indoor cabinet climate management for sensitive electronics

Procurement Notes

Verify that the target enclosure model is compatible with the HB16 series mounting specifications before purchase. Confirm that the facility provides the required 230 VAC single-phase power supply. Ensure the application environment remains within the specified 50 to 125 degrees F operating range. Check local regulations regarding refrigerant handling during installation or disposal.

Selection Notes

Select this unit when 8,000 Btu/hr cooling capacity is sufficient for the specific enclosure heat load. Choose this model if the installation requires a top-mount configuration rather than side or rear mounting. This unit is appropriate for indoor use where NEMA 12 protection against dust and dripping non-corrosive liquids is required. Verify voltage compatibility with the available site power infrastructure.

Part Context

This component belongs to the nVent Hoffman Genesis line of enclosure air conditioners. The Genesis series focuses on sealed, maintenance-free cooling solutions for industrial control panels. The HB16 designation indicates the specific series and form factor within the Hoffman product portfolio.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
