HBLS1005-56NJ_M

Overview

The HBLS1005-56NJ_M is a fixed multilayer inductor manufactured by Max Echo, designed for surface mount applications. It features an unshielded construction with a ceramic core and rectangular form factor. The component provides an inductance of 56 nH with a tolerance of ±5%. It supports a maximum DC current of 200 mA and exhibits a maximum DC resistance of 1.2 Ohms. The device operates within a temperature range of -55°C to 125°C and utilizes a 0402 (1005 Metric) package.

Feature Summary

• Unshielded multilayer ceramic construction for high-frequency stability
• Compact 0402 surface mount footprint for space-constrained designs
• Robust thermal performance across extended industrial temperature ranges

Applications

• RF circuit filtering and impedance matching
• High-frequency signal processing modules
• General purpose inductive components in embedded systems

Procurement Notes

Verify the manufacturer part number against official Max Echo documentation to ensure authenticity. Confirm that the specific ordering suffix matches the required electrical parameters and packaging specifications. Cross-reference the datasheet values for inductance, current rating, and resistance to validate compliance with design requirements before finalizing procurement orders.

Selection Notes

Select this component when a compact, unshielded inductor is required for RF or general-purpose applications. Ensure the 200 mA current rating meets the circuit's operational demands. Consider the lack of shielding if electromagnetic interference isolation is critical. Verify compatibility with standard 0402 reflow soldering profiles and check availability of the specific Max Echo series variant.

Part Context

This component belongs to the Max Echo HBL series of multilayer high-frequency inductors. These devices utilize ceramic technology to provide stable inductance values in small packages. The series is engineered for surface mount technology, offering reliability in consumer electronics and industrial equipment where space efficiency and consistent high-frequency performance are prioritized.

Replacement Considerations
