HBS610-13

$0.25

Description：BRIDGE RECT 1PHASE 1KV 6A HBS
Series：-

SKU:67e40930362b Category: Bridge Rectifiers Brand: Diodes Incorporated

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：BRIDGE RECT 1PHASE 1KV 6A HBS
Series：-
Mfr：Diodes Incorporated
Package：Tape & Reel (TR)
Diode Type：Single Phase
Technology：Standard
Voltage - Peak Reverse (Max)：1 kV
Current - Average Rectified (Io)：6:00 AM
Voltage - Forward (Vf) (Max) @ If：960 mV @ 6 A
Current - Reverse Leakage @ Vr：5 µA @ 1000 V
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：4-SMD, Gull Wing
Supplier Device Package：HBS
Grade：-
Qualification：-

Download product information

HBS610-13

Overview

The HBS610-13 is a single-phase, surface mount glass passivated bridge rectifier manufactured by Diodes Incorporated. It features an average rectified output current of 6.0 A and a peak repetitive reverse voltage of 1,000 V. The device utilizes the HBS package with a low profile design. Key electrical parameters include a maximum forward voltage drop of 0.96 V at 6 A and a leakage current of 5 μA at 1,000 V. It supports a non-repetitive peak forward surge current of 170 A (8.3 ms) and operates within a temperature range of -55 °C to +150 °C.

Feature Summary

Glass passivated die construction for enhanced reliability
Miniature surface mount package designed to save printed circuit board space
High forward current capability up to 6.0 A with high heat dissipation
Low forward voltage drop for improved efficiency

Applications

Fast charging systems
Switching power supplies
USB PD adapters
3-in-1 DTV power boards

Procurement Notes

Verify component authenticity through authorized Diodes Incorporated channels or certified distributors. Confirm RoHS compliance and lead-free finish specifications against the latest datasheet revision DS42426 Rev. 3-2. Ensure packaging matches the specified 2,500 units per tape and reel format. Validate marking codes for product type and date consistency prior to integration.

Selection Notes

Select this component for applications requiring a 1,000 V blocking voltage and 6.0 A continuous current in a compact surface mount form factor. Consider the thermal resistance characteristics when designing heatsinking solutions. Verify that the operating environment remains within the specified -55 °C to +150 °C junction temperature range for optimal performance.

Part Context

The HBS610 belongs to the HBS series of surface mount bridge rectifiers from Diodes Incorporated. This series is engineered for general-purpose AC-to-DC full-wave rectification. The specific model provides a balance of high current handling and low profile dimensions, suitable for modern electronics where board space is constrained.
