HCI1608F-39NJ-M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists TAI-TECH Advanced Electronics Co., Ltd.. Its product description is IND 39NH 0.6OHM 300MA. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for HCI1608F-39NJ-M
- Description：IND 39NH 0.6OHM 300MA
- Series：HCI1608F
- Mfr：TAI-TECH Advanced Electronics Co., Ltd.
- Package：Tape & Reel (TR),Cut Tape (CT)
- Type：Multilayer
- Material - Core：-
- Inductance：39 nH
- Tolerance：±5%
- Current Rating (Amps)：300 mA
- Current - Saturation (Isat)：-
- Shielding：Unshielded
- DC Resistance (DCR)：600mOhm Max
- Q @ Freq：12 @ 100MHz
- Frequency - Self Resonant：1.1GHz
- Ratings：-
- Operating Temperature：-55°C ~ 105°C
- Inductance Frequency - Test：100 MHz
- Mounting Type：Surface Mount
- Package / Case：0603 (1608 Metric)
- Supplier Device Package：603
- Size / Dimension：0.063" L x 0.031" W (1.60mm x 0.80mm)
- Height - Seated (Max)：0.037" (0.95mm)
- Features：-
Fixed Inductors datasheet and documents for HCI1608F-39NJ-M
Fixed Inductors Overview
The HCI1608F-39NJ-M is a high-frequency chip inductor from TAI-TECH Advanced Electronics Co., Ltd. It features an unshielded multilayer construction housed in a 0603 (1608 Metric) package designated as L0603. The component provides an inductance of 39 nH with a maximum DC resistance of 600 mOhm and a rated current of 300 mA. This lead-free device is designed for surface-mount applications requiring compact magnetic components.
Fixed Inductors Feature Summary
- Unshielded multilayer inductor design
- High-frequency chip inductor configuration
- Lead-free manufacturing process
Fixed Inductors Applications
- General electronic circuit filtering
- Signal processing applications
- Compact power supply designs
Fixed Inductors Procurement Notes
Verify the specific manufacturer datasheet to confirm electrical tolerances and thermal characteristics. Ensure the 0603 footprint matches the target PCB layout. Confirm that the 300 mA current rating meets the operational requirements of the intended circuit application before finalizing procurement.
Fixed Inductors Selection Notes
Select this component when a low-inductance value near 39 nH is required for high-frequency signal paths. The unshielded design may influence placement relative to sensitive traces. Verify that the 600 mOhm resistance limit aligns with efficiency targets for the specific power or signal line being implemented.
Fixed Inductors Part Context
Tai-Tech Advanced Electronics Co., Ltd. was established in 1992, focusing on R&D and sales of multilayer chip ferrite beads and inductive components. The company specializes in magnetic materials and inductive components, including EMI suppression filters and common mode chokes, serving various industrial and consumer electronics markets.
Fixed Inductors Replacement Considerations
Consult official distributor catalogs for direct substitutes within the same series or equivalent specifications. Verify pin compatibility and impedance curves when considering alternative manufacturers. No public substitute part numbers are confirmed in available documentation.
