Product Detailed Parameters
- Description：HDAS RECEPTALE 11 STRAIGHT PC TA
- Series：HDAS
- Mfr：Amphenol Aerospace Operations
- Package：Tray
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board
- Number of Positions：11
- Number of Positions Loaded：All
- Pitch - Mating：0.075" (1.91mm)
- Number of Rows：3
- Row Spacing - Mating：0.075" (1.91mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Threaded
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：50.0µin (1.27µm)
- Insulation Color：Black
- Insulation Height：0.315" (8.00mm)
- Contact Length - Post：0.270" (6.86mm)
- Operating Temperature：-65°C ~ 150°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Tin
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：Jackscrews, Mating Flange, Mounting Flange
- Current Rating (Amps)：4.5A per Contact
- Voltage Rating：750V
Download product information
Overview
The HDASE011YD-000LF is an 11-position rectangular MIL Spec receptacle connector from the Amphenol HDAS series. It features a 0.075 inch (1.91mm) pitch and utilizes straight PC tail contacts for through-hole PCB mounting. The connector employs gold plating on contacts and is designed for high-density applications requiring reliability in extreme conditions, exceeding MIL-DTL-55302 standards.
Feature Summary
- Utilizes star-clamp technology with six contact teeth for secure signal transmission
- Features cylindrical machined pins to ensure robust mechanical stability
- Constructed with LCP material compatible with high-temperature soldering processes
- Includes side rails on male connectors to protect contacts from external damage
Applications
- Aerospace systems requiring high vibration resistance
- Military equipment operating in extreme environmental conditions
- High-density PCB installations where space and cost efficiency are critical
Procurement Notes
Verify that the specific part number matches the required 11-position configuration and straight PC tail contact style. Confirm that the lead-free designation aligns with RoHS compliance requirements for your assembly process. Ensure the through-hole mounting specification is compatible with your PCB design constraints before finalizing procurement.
Selection Notes
Select this component when high contact density and reliability under extreme conditions are prioritized over standard commercial connectors. The HDAS series offers reduced spacing compared to traditional rectangular connectors. Consider the cylindrical machined pin design for superior performance in high-vibration environments compared to stamped contacts.
Part Context
This connector belongs to the HDAS high-performance PCB connector family by Amphenol Aerospace Operations. The series is engineered for aerospace and military markets, offering a simple yet reliable design. It addresses the need for increased contact density while maintaining performance beyond standard MIL-DTL-55302 specifications.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing mating interfaces if considering alternative rectangular connector series.
